Amplifier Research 50s1g4a Solid State Broad Band Amp: 0.8 - 4.2 Ghz, 50w

US $25,950.00

Oceanside, California, United States
Jan 29th

Open on mobile:
QR code

AMPLIFIER RESEARCH 50S1G4A *Call (760) 806-6600 to RENT this item* DESCRIPTION The Amplifier Research 50S1G4A Amplifier is a solid state, self-contained, air-cooled, broadband amplifier designed for applications where instantaneous bandwidth, high gain and linearity are required. Housed in a stylish contemporary cabinet, the unit is designed for benchtop use, but can be removed from the cabinet for immediate equipment rack mounting. The AR 50S1G4A Amplifier, when used with a sweep generator, will provide a minimum of 50 watts of RF power. Included is a front panel gain control which permits the operator to conveniently set the desired output level. The 50S1G4A is protected from RF input overdrive by an RF input leveling circuit which controls the RF input level to the RF amplifier first stage when the RF input level is increased above 0 dBm. The RF amplifier stages are protected from over-temperature by removing the DC voltage to them if an over-temperature condition occurs due to cooling blockage or fan failure. There is a digital display on the front panel to indicate the operate status and fault conditions if an over-temperature or power supply fault has occurred. The unit can be returned to operate when the condition has been cleared. The 50S1G4A digital panel provides control of all amplifier functions both locally and remotely via IEEE-488 (GPIB) or RS-232 interfaces. The low level of spurious signals and linearity of the Amplifier Research 50S1G4A make it ideal for use as a driver amplifier in testing wireless and communication components and subsystems. It can be used as a test instrument covering multiple frequency bands and is suitable for a variety of communication technologies such as CDMA, W-CDMA, TDMA, GSM etc. It is also suitable for EMC Test applications where undistorted modulation envelopes are desired. Specifications of the Amplifier Research 50S1G4A include: RATED POWER OUTPUT................................................50 watts minimum INPUT FOR RATED OUTPUT ..........................................1.0 milliwatt maximum POWER OUTPUT @ 3dB COMPRESSSION Nominal ................................................................70 watts Minimum ...............................................................50 watts POWER OUTPUT @ 1dB COMPRESSION Nominal ................................................................60 watts Minimum ...............................................................40 watts FLATNESS .....................................................................±1.5 dB typical ±2.0 dB maximum FREQUENCY RESPONSE ...............................................0.8–4.2 GHz instantaneously GAIN (at maximum setting) ...........................................47 dB minimum GAIN ADJUSTMENT (Continuous Range)................................................10 dB minimum (4096 steps remote) INPUT IMPEDANCE.......................................................50 ohms, VSWR 2.0:1 maximum OUTPUT IMPEDANCE ...................................................50 ohms, nominal MISMATCH TOLERANCE*..............................................100% of rated power without foldback. Will operate without damage or oscillation with any magnitude and phase of source and load impedance. *See Application Note #27. MODULATION CAPABILITY ...........................................Will faithfully reproduce AM, FM, or pulse Modulation appearing on the input signal THIRD ORDER INTERCEPT .............................................The third order intercept points for this chart have been determined using two tones spaced 1 MHz apart. This is typical for WCDMA systems. Closer tone spacing such as 60 kHz generally provides about a 1db to 3db improvement in the IP. HARMONIC DISTORTION.............................................Minus 20 dbc max at 50 watts SPURIOUS ....................................................................Minus 73 dbc Typ. PHASE LINEARITY..........................................................±1.0 deg/100 MHz, Typ PRIMARY POWER (Selected Automatically) ......................90-132, 180-264 VAC 50/60 Hz, single phase 600 watts maximum CONNECTORS RF..........................................................................Type N female REMOTE INTERFACES IEEE-488............................................................24 pin RS-232 ..............................................................9 pin Subminiature D SAFETY INTERLOCK......................................................15 pin Subminiature D COOLING....................................................................Forced air (self contained fans) Notes / Included Options: standard configuration *All of our equipment has been tested. Additional Calibration may be available upon request! ~Item sold with shown accessories, a power cord and manual on CD (when available)~ PAYMENT AND SHIPPING INFO Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. And although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. All orders also come with a limited 5-day ROR (Right of Return). This ROR is limited to goods found to be non-acceptable due to cosmetic defect (not previously disclosed) or an item not meeting manufacturer's spec as advertised. ROR does not apply to wrong item(s) ordered by customer, equipment that has been misused or damaged by customer's misuse (intentional or unintentional), or any orders damaged in transit. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your own shipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Equipment has been tested and is fully functional with a 30-day Warranty”
