Amprobe ACD-41PQ 1000A Power Quality Clamp Meter with Temperature DETAILS Digital clamp meter measures alternating current (AC) to 1,000 amp, direct current (DC) voltage and AC voltage to 600 volts (V), resistance to 1,000 ohms, frequency to 500 hertz (Hz) True RMS (root mean square) sensing meter provides accurate readings when measuring linear or non-linear loads, where the current or voltage has a sinusoidal or nonsinusoidal waveform Transformer clamp with 1.77" (45 mm) jaw opening measures current without touching or interrupting the circuit K-type thermocouple probe measures temperature Meets International Electrotechnical Commission (IEC) safety standard 61010 and is certified for category III installations up to 600V SPECIFICATIONS The Amprobe ACD-41PQ digital clamp meter is true RMS (root mean square) sensing, auto-ranging multimeter for measuring current, voltage, resistance, frequency, temperature, harmonics, power factor, and real, reactive, and apparent power in industrial electrical testing applications. It has a clamp that measures alternating current (AC) to 1,000 amp. The meter comes with detachable test leads that measure direct current (DC) voltage and AC voltage to 600 volts (V), resistance to 1,000 ohms, and frequency to 500 hertz (Hz). The clamp has two jaws that can close around an electrical conductor up to 1.77" (45 mm) in diameter to measure current without touching or interrupting the circuit. The meter comes with a K-type thermocouple probe for measuring temperature. Power factor, real power, reactive power, and apparent power readings provide data on the power efficiency of an electrical system. The meter measures fundamental total harmonic distortion (THD) and individual harmonics, which can degrade the quality of the power being supplied by the system. Automatic detection mode selects voltage or current function based on input. The peak hold reading displays the maximum measurement of a current or voltage surge. An audible continuity sensor confirms that the circuit conducts electricity. The hold function keeps the reading on the display, even after the meter is disconnected. The backlit liquid crystal display (LCD) is visible in low light. The unit automatically turns off after 17 minutes of non-use to conserve battery life, and a low-battery indicator signals when the meter's batteries need to be replaced. A finger guard on the body of the meter helps protect fingers from shock. This true RMS (root mean square) sensing meter provides accurate readings when measuring linear loads, such as standard induction motors and incandescent lights, where the current or voltage has a sinusoidal waveform, or non-linear loads, such as electronic devices or motors, where the current or voltage has a sinusoidal non-sinusoidal waveform. This auto-ranging meter automatically selects the correct operating range for the property being measured. The meter has a 4,000 count resolution for current measurements, a 6,000 count resolution for voltage measurements, and a 10,000 count resolution for power, ohm, and frequency measurements, meaning it can display up to 3,999 (3-3/4 digits), 5,999 (3-5/6 digits), and 9,999 units (4 digits), respectively, before the operating range needs to be changed. It meets International Electrotechnical Commission (IEC) safety standard 61010 and is certified for category III installations up to 600V, which covers items used with enclosed building circuit installations (service panel parts, branch circuits, and fixed installations that are connected directly to a building's AC power supply). The unit comes with a soft vinyl carrying case. Specifications Maximum alternating current (AC) input 1,000 amp Maximum AC voltage input 600 volts (V) Maximum DC voltage input 600V Maximum resistance detected 1,000 ohms Maximum frequency detected 500 hertz (Hz) Maximum active power detected 600 kilowatts (kW) Maximum reactive power detected 600 kilovolt amperes reactive (kVAR) Maximum apparent power detected 600 kilovolt amperes (kVA) Individual harmonics detected H1 to H51 Maximum total harmonic distortion detected 100% Temperature measurement range -58 to 572 degrees Fahrenheit (F)/50 to 300 degrees Celsius (C) Power supply 1.5V NEDA 24A or IEC lR03 AAA batteries (two, installed) Standards met and certifications International Electrotechnical Commission (IEC) and EN safety standard 61010-1; European Conformity (CE); Australia N10140; Underwriters Laboratories Weight 0.49 lb./224 g Dimensions 8.9 x 3.1 x 1.6 inches/224 x 78 x 40 mm (H x W x D) H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Clamp meters (also called clamp-on meters) measure electrical current without cutting through wires or touching or interrupting the electrical circuit. Available in handheld or benchtop models, clamp meters diagnose problems in electrical equipment, wiring, and power supplies. The meter's current clamp has two jaws that fit around a conductor to take measurements. All clamp meters test for current. Some come with test leads and inputs for measuring voltage, capacitance, and resistance. They display information either in analog or digital form. Factors that influence meter choice include the electrical properties to be measured, the anticipated range of results, and the desired level of protection against transient voltages determine meter choice. Safety ratings are based on the International Electrotechnical Commission's (IEC) standards for low-voltage test equipment. IEC 61010 delineates four overvoltage installation categories. In general, a meter with a category IV rating will provide more protection against transient voltages than a meter with a lower category rating. Amprobe manufactures electrical testing equipment for commercial, industrial, and home use. The company was founded in 1948 and is headquartered in Everett, WA. What?s in the Box? ACD-41PQ TRMS digital clamp meter (1) Set test leads (1) K-type thermocouple probe (2) 1.5V AAA batteries (installed) Carrying case with belt loop Instructions ADDITIONAL FEATURES Manufacturer: Amprobe Shipping Weight: 110 Product Dimensions: Width: 6.10 Length: 11.60 Height: 3.10 SHIPPING INFORMATION ● Our stock all ships from our US-based warehouses. ● Shipped via USPS or UPS or FedEx (depending on location and package weight) ● eBay Global Shipping Program - We are a part of eBay Global Shipping Program. This means that eBay will be responsible for shipping and import charges and times. We don't control the shipping times and import charges, which are based on your location in the world. You can find all the info in the eBay listing! RETURN & REFUND POLICY ● We offer a 30 day return/exchange policy for our products. ● You can choose refund or exchange if you are dissatisfied for any reason with your product. ● Only factory defects are accepted as a reason for a return. In the case of factory defects, we will replace the product for you. ● When returning an item, it must be in all of the original packaging and include all of the original accessories or items that came with it. The item and package should be in original and perfect condition. ● You will be required to cover shipping on the return of defective items. ● All returns MUST be done within 30 days of date of purchase. Please note that we cannot give refunds or replacements after the 30 day limit has expired. ● When sending in a return, please note that it can take up to 7 business days for the return to be processed. We do our best to process as quickly as possible. ● Buyers outside the U.S.A please note - ALL of our electrical appliances sold in our store are 110-120V. ● Return policy for buyers outside the U.S.A - We offer to return the items within 30 days. The BUYER will ship the item at his own cost. We are extremely fair, and in the rare event of something out of the ordinary happening with our products or shipping, we will gladly work with you to find a solution. ABOUT USA Daily Deals Since 2010 USA Daily Deals have been available to online customers, offering a variety of brand new products at great prices. All of our products ship directly from our different warehouses across the United States so you get your items quickly and in perfect condition. We know how important it is for you to get what you ordered and get it fast. Our products are a 100% authentic and brand new. We work with the biggest suppliers of high quality products to bring you only the best items. It is very important to us that we put our customers first and you will see this reflected in every transaction with us. We consider it a top priority that our customers are happy and in the rare event that they are not, we do everything we can to fix the situation. No customer will walk away from our store unhappy. If there?s a problem, just let us know and we fix it. We guarantee you only the best experience when shopping with us! Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining< /li> Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
