Analog Discovery 2 Usb Oscilloscope, Logic Analyzer And Power Supply

US $458.85

Swanton, Vermont, United States
Aug 13th

Open on mobile:
QR code

Description 16-channel digital logic analyzer (3.3V CMOS, 100Msample/sec) Single channel voltmeter (AC, DC, ±25V) Digital Bus Analyzers (SPI, I²C, UART, Parallel) Two input/output digital trigger signals for linking multiple instruments (3.3V CMOS) The Analog Discovery 2 USB Oscilloscope, Logic Analyzer and Power Supply is a USB oscilloscope and multi-function instrument that allows users to measure, visualize, generate, record, and control mixed-signal circuits of all kinds. Developed in conjunction with Analog Devices and supported by Xilinx University Program, Analog Discovery 2 is small enough to fit in your pocket, but powerful enough to replace a stack of lab equipment, providing engineering students, hobbyists, and electronics enthusiasts the freedom to work with analog and digital circuits in virtually any environment, in or out of the lab. The analog and digital inputs and outputs can be connected to a circuit using simple wire probes; alternatively, the Analog Discovery BNC Adapter and BNC probes can be used to connect and utilize the inputs and outputs. Driven by the free Wave Forms 2015 (Mac, Linux and Windows Compatible) software, Analog Discovery 2 can be configured to work as any one of several traditional instruments. Specifications 16-channel digital logic analyzer (3.3V CMOS, 100Msample/sec) 16-channel pattern generator (3.3V CMOS, 100Msample/sec) 16-channel virtual digital I/O including buttons, switches, and LEDs – perfect for logic training applications Two input/output digital trigger signals for linking multiple instruments (3.3V CMOS) Single channel voltmeter (AC, DC, ±25V) Network analyzer – Bode, Nyquist, Nichols transfer diagrams of a circuit. Range: 1Hz to 10MHz Spectrum Analyzer – power spectrum and spectral measurements (noise floor, SFDR, SNR, THD, etc.) Digital Bus Analyzers (SPI, I²C, UART, Parallel) Two programmable power supplies (0…+5V , 0…-5V). The maximum available output current and power depend on the Analog Discovery 2 powering choice: 250mW max for each supply or 500mW total when powered through USB 700mA max or 2.1W max for each supply when using an external wall power supply What's Included Analog Discovery 2 One regular-sized project box (without sticker sheet) One USB A to micro B programming cable One 2x15 flywire signal cable assembly 5-pack of 6-pin male headers One ferrite cable snap-on Multimedia

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Digilent
MPN	410-321
Type	Digilent
UPC	Does not apply
