Angle Gauge Block Adjustable Driller Equipment Grinder Milling Durable

C $48.13

suzhou, China
Aug 2nd

Open on mobile:
QR code

Product Description Angle gauge block Adjustable Driller Equipment Grinder Milling Durable Features: *75x25x36mm Precision Mini Adjustable Angle Gauge V Block Milling 0 Degree To 60 Degree *Made of high-quality steel, good wear resistance, not easy to rust, long service life *Laser scale deep writing, easier to read, and the writing is not worn *Precision grinding of flatness and verticality between working faces to 0.01mm *The angle can be adjusted according to the vernier indicator, and the nut can be tightened *Uses: On the milling machine, planer, grinder, and drilling machine, use the adjustable angle gauge to scribe or cooperate with other fixtures to fix the workpiece and process, such as machining bevels, drilling inclined holes, etc. Specifications: *Name: Adjustable Angle Gauge *Material: Stainless Steel *Measurement accuracy: ±0.01mm *Size: 75*25*36mm (Approx) Usage: (1) Loosen the screw, pull the V-shaped block to rotate along the guide rail on the base to find the target angle (2) Use the cursor principle reading, the graduation on the main scale is 1 °, the cursor index is 10'. The "0" line on the upper line is aligned with the "0" line on the main scale, indicating that the A measurement surface is parallel to the reference plane, and the B reference plane is perpendicular to the reference plane 1. When the cursor "0" line is on the right side of the main line "0" line, the degree is read by the cursor "0" line, and the score is read by the scale on the right side of the cursor "0" line (reading is the same as the vernier caliper) Degree (°) and minute (') indicate that the A and B measuring surfaces turn counterclockwise. 2. When the cursor "0" line is on the left of the main line "0" line, the degree is still read with the cursor "0" line, and the score is read with the scale on the left of the cursor "0" line. Degree: (°), Minute: (') A, B measurement angle is turned clockwise. 3. After the angle is adjusted to the target value, tighten to make the V-block and the base tight Main Technical Indicators: (1) When the measuring surface A is parallel to the base surface and the measuring surface B is perpendicular to the reference surface, the "0" line of the cursor and the line of the main scale "0" are not more than 3', and the point scale at both ends of the cursor and the main scale are not 11°. The coincidence degree is not more than 5'; otherwise, after tightening the screw to align the main scale 0° line with the cursor "0" line, the parallelism between the A measuring surface and the reference surface is not more than 0.01mm, and the perpendicularity between the B measuring surface and the reference surface is also Not more than 0.01mm (2) In the fixed state, the indication error of the adjustable angle gauge is not more than ±10' Package Contents: 1*Adjustable Angle Gauge 1*Hex Wrench Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Country/Region of Manufacture	China
MPN	Does Not Apply
Material	Stainless Steel
Package Contents	Set
Size	752536mm
UPC	Does not apply
