Anritsu Mt9083a2 Access Master Sm Mm Fiber Otdr W/ Power Meter & Vfl Mt9083a

US $4,895.00

Toledo, Ohio, United States
Jul 3rd

Open on mobile:
QR code

The Following Items Are Included: Anritsu MT9083A2 Access Master SM MM Fiber OTDR (BC# 32550-L/T*) SM OTDR Source: 1310nm 1550nm MM OTDR Source: 850nm 1300nm (2) SC Connectors For Source Power Meter: 850nm 1300nm 1310nm 1383nm 1490nm 1550nm 1625nm 1650nm SC Connector For Power Meter (2) SM SC-SC Fiber Cables MM SC-SC Fiber Cables (4) Fiber Wipes Protective Screen Cover AC Adapter/Charger Power Cord USB PC interface Cable User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Anritsu MT9083A2 Access Master SM 1310 / 1550nm MM 850 / 1300nm OTDR w/ Power Meter & Visual Fault Locator Dynamic Range: 1310 / 1550 nm : 39 / 37.5 dB 850 / 1300 nm : 29 / 28 dB Power Meter: - 850nm - 1300nm - 1310nm - 1383nm - 1490nm - 1550nm - 1625nm - 1650nm Visual Fault Locator Includes Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY ACCESS Master Key Features Ready to test in about 15 seconds…and all day without recharging Specialized testing modes simplify operation High resolution and high dynamic range ensure quick and through fiber evaluation Intelligent analysis software identifies problem splices, connectors and even macrobends Rugged, sealed design provides years of service in the most challenging environments IP testing option verifies throughput, frame loss and point-to-point connectivity Test up to four wavelengths with a single unit - single mode, multimode or both Unique in-service testing without the need for external filters Verify connector quality with optional connector inspection microscope Optimized for Verifying Pon Splitters Up to 1 128 Count Many OTDRs claim to be able to test splitter-based, passive optical networks (PON) but the MT9083 delivers in a way others wish they could. With its high dynamic range and quick data acquisition, the MT9083 provides unparalleled resolution of single or closely spaced, cascaded splitters up to an industry-leading 1 128 count. Designed with the Features that Matter Most When buying products, you tend to choose ones that are innovative and from established companies. When you need to install and maintain optical networks, this should also apply. With over 50 years of combined OTDR design, Anritsu, delivers the features that matter. Having been in the test an measurement business for a long time, we understand that things like performance, portability, reliability, easy operation and of course price are important. Quick Startup The ACCESS Master is ready for measurement about 15 seconds after power-on so productive work can start immediately. Long Battery Life Since AC power is not always available where you need it, especially at fiber pedestals, the MT9083 typically provides up to 8 hours of operation on a single charge. This coupled with an optional car cord (for cigarette lighter operation) guarantees the MT9083 is ready when you are. Portable With its light weight design and user friendly dimensions, the MT9083 is perfect for the outside plant environment and can easily be managed with one hand. The shoulder strap (part of the protector option) further increases portability when travelling from the truck to the testing site. Rugged The MT9083 features a solid casework with no fans or vents to keep dust or moisture from entering the unit.In addition, the protector option (MT9083A/B/C-010) includes rubber bumpers and a display cover for additional protection from those minor mishaps. Generous Data Storage With the ability to store up to 1,000 traces in internal memory and up to 30,000 via a USB device, the MT9083 offers plenty of storage for collecting and managing data. No Experience Required With the ACCESS Master, the experience is built in. With specialized testing modes, automatic parameter selection, PASS/FAIL indicators as well as features to virtually eliminate the chance to get "bad" results, the MT9083 can make anyone seems like a 20 year veteran. Let it help you master your network. Easy "drag and drop" File Transfers When the MT9083 is connected to a PC via a USB cable, the internal memory of the ACCESS Master can be directly accessed. Data can be selected, dragged and dropped into the PC memory, greatly simplifying file transfers. The MT9083 also supports use of USB memory sticks. Common OTDR Data Format The MT9083 supports the universal Telcordia SR-4731 (issue 2) format making it compatible with not only legacy Anritsu and NetTest products, but with many other vendors data. Free and Simple Software Upgrades Firmware upgrades are easily performed via USB and available from the Anritsu website for registered users or through Anritsu customer support. Active fiber check Not only can OTDR measurements be effected when the optical fiber is in-service but there is a potential risk of damage to the transmitter and OTDR receiver. To prevent these problems, the MT9083 verifies if light is present before starting measurement and will not transmit if it is. An on-screen warning and internal OTDR protection are also part of this useful feature. Integrated Macrobend Detection With many technicians making the switch from copper installations to optical fiber, installation issues such as macrobends are bound to occur. To help prevent this, Anritsu has developed a macrobend detection feature for the MT9083 that will alert technicians when a possible macrobend is present. This provides a higher quality of service for the customer and eliminates costly troubleshooting for you. Wavelengths for Today's Networks Sometimes you just need more than the traditional 1310 and 1550 nm wavelengths to certify your next generation networks. The MT9083 offers a host of specialized wavelengths including 1383 nm for water peak verification of CWDM carrying fibers, 1650 nm (with integrated filter) for live fiber troubleshooting, 1490 nm for verification of voice, data and IP based video services and 780 nm for in-service troubleshooting of FTTx networks - without the need for any additional filters. Specifications: Dimensions Mass 270 (W) 165 (H) 61 (D) mm, 10.6 6.5 2.4 inches 1.6 kg, 1.9 kg including battery Display 7-inch TFT-LCD (800 480, with LED backlight), Indoor/Outdoor type Interface USB 1.1, Type A 1 (memory), Type B 1 (USB mass storage) Data Storage Internal memory: 440 MB (up to 1000 traces), External memory (USB): up to 30,000 traces with 512 MB Power Supply 12 V(dc), 100 V(ac) to 240 V(ac), Allowable input voltage range: 90 V to 264 V, 50 Hz/60 Hz Battery Type: Lithium-ion Operating Time: 12 hours, Telcordia GR-196-CORE Issue 2, September 2010 Recharge Time: <5 hours (power off) Power Saving Functions Backlight off: Disable/1 to 99 minutes Auto shutdown: Disable/1 to 99 minutes Vertical Scale 0.13, 0.33, 0.65, 1.3, 3.25, 6.5, 13 dB/div IOR Setting 1.400000 to 1.699999 (0.000001 steps) Units km, m, kft, ft, mi Languages User selectable (English, Simplified Chinese, Traditional Chinese, French, German, Italian, Korean, Portuguese, Russian, Spanish and Swedish - contact Anritsu for availability of others) Sampling Points Normal: 5001, High density: 20001 or 25001, Very high density: 100,001 or 150,001 Sampling Resolution 5 cm (min.) Reflectance Accuracy Single mode: ±2 dB, multimode: ±4 dB Distance Accuracy ±1 m ±3 measurement distance 10–5 ± marker resolution (excluding IOR uncertainty) Distance Range Single mode: 0.5, 1, 2.5, 5, 10, 25, 50, 100, 200, 300 km Multimode: 0.5, 1, 2.5, 5, 10, 25, 50, 100 km Testing Modes Fiber Visualizer: Provides end/break location, end to end loss, fiber length, easy graphical summary, PDF report Standard OTDR: User selectable automatic or manual set-up Construction OTDR: Automated, multi-wavelength testing Light source: Stabilized Light source (CW, 270 Hz, 1 kHz, 2 kHz output) Fiber Event Analysis Auto or manual operation, displayed in table format User defined PASS/FAIL thresholds: - Reflective and non-reflective events: 0.01 to 9.99 dB (0.01 dB steps) - Reflectance: –70.0 to –20.0 dB (0.1 dB steps) - Fiber end/break: 1 to 99 dB (1 dB steps) Number of detected events: up to 99 Macrobend detection OTDR Trace Format Telcordia universal. SOR, issue 2 (SR-4731) Other Functions Real time sweep: 0.15 sec. Loss modes: 2-point loss, dB/km, 2-point LSA, splice loss, ORL Averaging modes: Timed (1 to 3600 sec.) Live Fiber detect : Verifies presence of communication light in optical fiber Connection check: Automatic check of OTDR to FUT connection quality Trace overlay and comparison, Template function, USB keyboard support, Remote control, Video output to PC Password protection feature Environmental Conditions Operating temperature and humidity: –10° to +50°C, <80% (non-condensing) Storage temperature and humidity: –20° to +60°C, <80% (non-condensing) Vibration: Conforming to MIL-T-28800E Class 3 Dust proof: MIL-T-28800E (Dust Exposure) Class 2 Drip proof: IP51 (IEC 60529), JIS C 0920 TYPE I EMC EN61326-1, EN61000-3-2 LVD EN61010-1 OTDR Specifications Wavelength 1310/1550 nm ±25 nm 850/1300 nm ±30 nm Fiber Type HYBRID (SMF/MMF) Pulse Width SMF: above MMF: 3, 10, 20, 50, 100, 200, 500, 1000, 2000, 4000 ns 850 nm: Not support 1000, 2000, 4000 ns Dynamic Range 39/37.5 dB 29/28 dB Deadzone (Fresnel) 1 m 80 cm (typ.) Deadzone (Backscatter) 5/5.5 m, 4/5 m (3/4 m typ.) For full Anritsu MT9083A2 product specifications, please click here: Anritsu MT9083A2 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Anritsu
Model	MT9083A2
MPN	MT9083A2
