Anritsu Mw82119a Pim Master; 1900 Mhz

US $1,995.00

Marietta, Georgia, United States
Jul 26th

Open on mobile:
QR code

Powered by Frooition Avalon eBay Store About Avalon Contact Us Customer Feedback Newsletter Add to Favorite Sellers PIM Testers Sweep Gear Antenna Alignment Tools OTDRs Fiber Optic Testers Handheld Spectrum Analyzers Cable Compression RF Safety Fusion Splicers RF Power Amplifiers Transient Generators EMC Receivers | EMI Analyzers Spectrum Analyzers Signal Generators ESD LISNs Oscilloscopes Power Supplies & Loads Network Analyzers Coupling/Decoupling Networks RF Power, Noise, Other CAL Test & Measurement Electrical TEST WITH CONFIDENCE® All Items See our eBay store for more great items >> Shop Categories PIM TestersSweep GearAntenna Alignment ToolsOTDRsFiber Optic TestersHandheld Spectrum AnalyzersCable CompressionRF SafetyFusion SplicersRF Power AmplifiersTransient GeneratorsEMC Receivers | EMI AnalyzersSpectrum AnalyzersSignal GeneratorsESDLISNsOscilloscopesPower Supplies & LoadsNetwork AnalyzersCoupling/Decoupling NetworksRF Power, Noise, OtherCAL Test & MeasurementElectrical Helpful Links Add to Favorite Sellers Sign up to Newsletter View Feedback Contact Seller Visit seller's eBay Shop About Seller Page Anritsu MW82119A PIM Master; 1900 MHz Anritsu MW82119A PIM Master; 1900 MHz Item Description The Anritsu MW82119A is a battery-operated, high power Passive Intermodulation (PIM) testing solution for the major wireless standards in use around the world. The PIM Masters small size and light weight, combined with battery operation, make it the ideal solution for verifying PIM performance at difficult to access sites such as Remote Radio Head (RRH) installations or indoor Distributed Antenna Systems (DAS). The MW82119A is able to perform the following measurements enabling test technicians to quickly find and eliminate PIM problems found at the cell site: PIM versus Time Noise Floor Swept PIM Distance-to-PIM (DTP) The PIM Master includes Anritsu's patented Distance-to-PIM (DTP) technology for accurately determining the location of PIM faults both inside the feed system as well as beyond the antenna. This technology becomes critically important for fault finding DAS installations due to the complexity of the feed system and a large number of RF interconnects. Without DTP, finding and eliminating PIM requires a process of elimination involving the movement of low PIM loads in the network until the PIM problem disappears. This process is not only time consuming, but it also means that good connections may be opened (and potentially damaged) in the process of locating PIM problems. Distance-to-PIM allows technicians to quickly and efficiently locate PIM sources at a site resulting in quicker site repairs and lower cost. As with all Anritsu Handheld products, the MW82119A has been designed and tested to rigorous standards for shock, vibration and temperature extremes to ensure reliable service in an outdoor environment. Standard Accessories: Soft Carrying Case, Screen Access Shoulder Strap Stylus with Coiled Tether Li-Ion Battery Pack; 11.1V, 7500 mAH for PIM/BTS AC/DC Power Supply; 1 meter 12 volt output cable Automotive Cigarette Lighter/12 Volts DC Adapter Ethernet Cable USB A - 5 PIN Mini-B Cable Calibration Certificate Specifications: Measurements PIM vs. Time: 3rd, 5th, and 7th order intermodulation product when in receive band (user selectable) Distance-to-PIM: Distance and relative magnitude of multiple PIM sources Swept PIM: 3rd, 5th, and 7th order intermodulation product when in receive band (user selectable) Noise Floor: Noise Floor vs. Time at selected IM product frequency Instrument Setup Parameters Frequency: Carrier F1, Carrier F2, Intermodulation Order (3rd, 5th, 7th) Amplitude: Ref Value, Scale, Auto Range (On/Off), Amplitude Tone (On/Off) Setup: Output Power, Test Duration (1s to 1,200s) Limit Lines: Limit (Upper/Lower), On/Off, Limit Move, Limit Alarm (On/Off, PASS/FAIL indicator) DTP: Cable Velocity, Distance PCS/AWS Tx1: 1930MHz to 1940MHz Tx2: 1955MHz to 1995MHz Tx3: 2110MHz to 2155MHz Rx1: 1850MHz to 1910MHz (using Tx1 and Tx2) Rx2: 1710MHz to 1755MHz (using Tx1 and Tx3) PIM Master Connectors Test Port: 7/16 DIN, female, 50? Dual USB Type A: 2x Type A (connect USB Flash Drive and USB Power Sensor) USB Mini-B: 1x Mini-B (connect to PC for data transfer) External Power: 2.1 mm x 5.5 mm barrel connector, 12 to 15VDC, <5.0A Display Size: 213mm (8.4in) touch screen Resolution: 800 x 600 Electromagnetic Compatibility Australia and New Zealand: C-tick N274 Interference: EN 61326-1:2006 Emissions: EN 55011:2007 Immunity: EN 61000-4-2/-3/-4-4/-4-5/-4-6/-4-11 European Union: CE Mark, EMC Directive 2004/108/EC Sales and Delivery Sales and Delivery Payment Shipping Terms Returns Sales and Delivery SHOP BY CATEGORY Fiber Optic Testers Pim | Sweep Antenna Alignment Tools Spectrum | Signal Analyzers Transient Generators RF | HIRF Amplifiers Network Analyzers Signal Generators Automotive Avalon eBay Store About Avalon Contact Us Customer Feedback Newsletter Add to Favorite Sellers Powered by Frooition Frooition | No-js Template | eBay design, eBay store design, eBay shop design, eBay template design, eBay listing design (ver:froo_no_js) This listing is currently undergoing maintenance, we apologise for any inconvenience caused.

“In good condition”

Brand

Anritsu

MPN

MW82119A-0190

EAN

Does Not Apply
