Anritsu Site Master S331e Cable & Antenna Analyzer Sitemaster W/ Opts 10/19/21

US $5,995.00

Toledo, Ohio, United States
Jul 9th

Open on mobile:
QR code

The Following Items Are Included: Anritsu Site Master S331E w/ Options: (BC# 42675) Option 10: Bias Tee Option 19: High-Accuracy Power Meter Option 21: 2-Port Transmission Measurements 7 Piece 7/16 DIN Adapter Kit: 7/16 DIN Male To 7/16 DIN Male Adapter 7/16 DIN Female To 7/16 DIN Female Adapter 7/16 DIN Male To N Male Adapter 7/16 DIN Male To N Female Adapter 7/16 DIN Female To N Male Adapter 7/16 DIN Female To N Female Adapter 7/16 DIN Male To 7/16 DIN Female Adapter Eagle CKT-050A Open/Short/Load Calibration Kit Armored Test Port Cable USB PC Interface Cable DC Car Charger AC Adapter/Charger Power Cord User Manual On CD-ROM Carrying Case (G) BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Anritsu SiteMaster S331E Cable & Antenna Analyzer ( Handheld ) 2MHz - 4.0GHz Installed Options: - Option 10: Bias Tee - Option 19: High-Accuracy Power Meter - Option 21: 2-Port Transmission Measurements This Unit Has A Color Touchscreen LCD Display! Includes Eagle CKT-050A Open/Short/Load Calibration Kit, Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 1 YEAR WARRANTY Anritsu introduces its eighth generation compact handheld Cable and Antenna Analyzers with Spectrum Analyzers for installation and maintenance of wireless networks. They feature the highest performance and the most capabilities ever offered by Anritsu in a compact handheld tester since introducing its first line sweeper in 1995. Cable and Antenna Analyzer Highlights Measurements: RL, VSWR, Cable Loss, DTF, Phase 2-port Transmission Measurement: High/Low Power Sweep Speed: 1 msec/data point, typical Display: Single or Dual Measurement Touchscreen Calibration: OSL, InstaCal™ , and FlexCal™ Bias Tee: 32 V internal The wireless communications market continues to evolve at a rapid pace. Operators and service providers have to maintain old networks while upgrading to the new 3G and 4G networks so as to keep up with changing consumer demands. They face the additional challenge of needing to ensure their networks are competitive from a reliability, quality, and cost perspective. As a result of all this, they expect more of the contractors and technicians who maintain their networks. To stay competitive, these contractors and technicians must maintain more base stations than before and complete a wide variety of tasks in the shortest time possible. Anritsu is pleased to introduce its eighth-generation compact handheld Site Master cable and antenna analyzer series with integrated spectrum analyzer. The new Site Master analyzers offer the same ease of use, ruggedness, and familiar menus as its predecessor S331D and S332D. In addition, Anritsu has enhanced the Site Master to address all the customer requirements and suggestions received over the years. Indeed, for more than 14 years, Anritsu’s Site Master has been the de facto standard for contractors, installers, and wireless service providers who need a portable and rugged cable and antenna analyzer. The Site Master reduces per site maintenance expense, maximizes system up-time, and breaks away from the traditional fix-after-failure maintenance mode by finding small problems before major failures occur. Radio frequency (RF) engineers and field technicians in the U.S. Navy, U.S. Air Force, and other global defense programs responsible for installing and maintaining communication systems use Site Master’s frequency domain reflectrometry (FDR)-based approach to improve the quality of their communication systems. Although the new Site Master resides in a modern platform that takes advantage of the latest technologies and is loaded with features that will enhance productivity, it provides more value for better productivity without giving up the familiar look and feel. INTEGRATED The Site Master is a 4 or 6 GHz cable and antenna analyzer that can be configured to include either a 4 or 6 GHz spectrum analyzer, 2-port transmission measurement with built-in 32V bias tee, an interference analyzer with spectrogram displays, a channel scanner, power meter, high accuracy power meter, and GPS receiver for time and location stamping. Because of its multi-functional capabilities, it eliminates the need for you to carry and learn multiple instruments. TRUSTED Anritsu builds upon its expertise in portable compact cable and antenna analyzers and spectrum analyzers. The Site Master is approved by all major operators and service providers worldwide. DESIGNED FOR FIELD USE The Site Master was designed specifically for field environments. It weighs less than 6 lbs and its field replaceable Li-Ion battery typically lasts for more than 4 hours. A new bright 8.4-inch color display provides visibility even in broad daylight. With an operating temperature range from -10° to 55 °C, the Site Master will work in the most extreme weather conditions. The analyzer is almost impervious to the bumps and bangs typically encountered by portable field equipment, and its ruggedized case and splash proof design allow you to depend on high performance anywhere, anytime. CONFIGURATION OVERVIEW Fucntion Description Cable and Antenna Analyzer, 2 MHz to 4 GHz Characterizes cable and antenna systems with return loss, cable loss, VSWR, distance-to-fault measurements. Also includes 1-port phase and Smith chart displays. Offers faster than 1 ms/data point sweep speed and a dual display. 2-port Transmission Measurement (Option 21) Provides high and low power settings for both TMA gain and antenna-antenna isolation measurements. Offers better than 80 dB dynamic range. Bias Tee (Option 10) Provides built-in 32 V bias tee that can be turned on as needed, and which eliminates the need to carry an external supply. High Accuracy Power Meter (Option 19) Connects high accuracy 6-, 8-, and 18 GHz USB power sensors with better than 0.16 dB accuracy. Power Meter (Option 29) Makes channelized transmitter power measurements. Interference Analyzer (Option 25) Includes the popular spectrogram display for monitoring intermittent signals over time. Channel Scanner (Option 27) Measures the power of multiple transmitted signals. CW Signal Generator (Option 28) Includes CW source to test low noise amplifiers, repeaters. (This requires an external CW generator kit.) GPS Receiver (Option 31) Provides location and UTC time information. Also improves the accuracy of the reference oscillator. Gated Sweep (Option 90) Views pulsed or burst signals such as WiMAX, GSM, and TD-SCDMAonly when they are on. AM/FM/PM Analyzer (Option 509) Analyze AM /FM/PM signals and measure FM/PM deviation, AM depth, SINAD, Total Harmonic Distortion and much more. Master Cable & Antenna analysis, anywhere, anytime The majority of the problems you find at a typical cell site are caused by problematic cables, pinched cables, corroded connectors, antennas, lightning strikes, rain getting into cables, and bullet holes. Degraded cable systems and badly positioned antennas affect overall system coverage and eventually result in dropped calls. Site Master’s FDR-based return loss and DTF measurements can pinpoint an antenna problem from ground level in a few seconds, enabling Site Master to identify small problems before they become big problems. Return Loss / VSWR Use the Site Master to make return loss and VSWR and verify that the cable and antenna system conforms to performance specifications. Cable Loss Cable Loss metrics measure the level of insertion loss within the cable feedline system. This measurement can be verified prior to deployment, when you have access to both ends. Site Master automatically calculates the average cable loss. Distance-To-Fault While the return loss metric is the best measurement to verify the health of a system, distance-to-fault (DTF) is used to troubleshoot systems and locate the problem. The Site Master’s DTF measurement uses the fast Fourier transform to convert frequency data to the time domain and displays signal anomalies with respect to distance. Using the standard trace math feature, you can monitor small relative changes over time. 2-port Transmission Measurements (Option 21) Cellular/PCS and 3G base stations today use diplexers, duplexers, and tower-mounted amplifiers to extend the coverage area. Site Master’s 2-port transmission measurement enables you to make gain, isolation, and insertion loss measurements as well as verify sector-to-sector isolation. BIAS TEE (option 10) The built-in bias tee can be turned on as needed to place +12 to +32V on the center conductor of the RF in port, eliminating the need for you to carry external supplies in the field. Enhance productivity with dual displays and instant calibration Dual Display The dual display enables users to view two cable and antenna measurements on the same display. Because you can control the top and bottom displays independently, you can set markers and limit lines on each display. This results in significant time savings as there’s no need to make two measurements. Smith Chart and 1-port Phase Display The cable and antenna analyzer also includes Smith chart and 1-port phase measurement displays for when you need to tune antennas and phase match cables. InstaCal™ Calibration Although you need to get the job done as quickly as possible, you still need to make reliable and accurate measurements. Anritsu’s InstaCal module enables you to make accurate calibrations at the end of the phase stable cable without connecting a short/open/load. You only need to connect the InstaCal module once and everything is done automatically. This calibration method can cut the calibration time by as much as 50 percent and still deliver accurate calibrations. Directivity specification for the InstaCal module is 38 dB for the entire frequency range, allowing you to make fast and accurate measurements in no time—and with no in-between connections. Standard OSL Calibration Open-Short-Load (OSL) calibration comes standard with the Site Master. All errors from source match, directivity, and frequency response are mathematically removed, allowing you to make accurate vector-corrected measurements. Directivity is usually the main contributor to measurement uncertainty, and corrected directivity of 42 dB or better is common using Anritsu’s precision components. FlexCal™ The Site Master’s FlexCal™ broadband calibration feature is an OSL-based calibration method that allows you to perform a broadband calibration and change the frequency range after calibration without having to recalibrate the instrument. RF Immunity Site Master’s special dithering RF immunity solution enables you to make accurate cable and antenna measurements even in the presence of strong RF activity from co-located cell sites. Cable and Antenna Analyzer highlights Return loss, VSWR, cable loss, DTF 2-port transmission measurements with 32V bias tee 1-port phase, Smith chart Optical DTF measurements Dual display mode capabilities Built-in, editable signal standard and cable standard lists Calibration: OSL Cal, FlexCal, InstaCal 137, 275, 551, 1102, 2204 data points < 1 msec per datapoint sweep speed Trace overlay and trace math to monitor changes with reference traces Marker table with automatic peak/valley markers GPS tagging Limit lines and alarming for providing reference standards GPS tagging of data to verify location of tests Master Software Tools for post-analysis and report generation Measurements Measurements VSWR Return Loss Cable Loss Distance-to-Fault (DTF) Return Loss Distance-to-Fault (DTF) VSWR 1-Port Phase Smith Chart Setup Parameters Measurement Display Single/Dual Measurement Display with independent markers Frequency Start/Stop, Signal Standard, Start Cal DTF Start/Stop, DTF Aid, Units (m/ft), Cable Loss, Propagation Velocity, Cable, Windowing Windowing Rectangular, Normal Side Lobe, Low Side Lobe, Minimum Side Lobe Amplitude Top, Bottom, Auto Scale, Full Scale Sweep Run/Hold, Single/Continuous, RF Immunity (High/Low), Data Points, Averaging/Smoothing, Output Power (High/Low) Data Points 137, 275, 551, 1102, 2204 Markers Markers 1-6 (On/Off), Delta Makers 1-6 (On/Off), Marker to Peak/Valley, Marker Table Traces Recall, Copy to Display Memory, No Trace Math, Trace ± Memory, Trace Overlay Limit Line On/Off, Single Limit, Multi-segment (41), Limit Alarm, Clear Calibration Start Cal, Cal Type (Standard/FlexCal™) Save/Recall Setups, Measurements (.vna, .dat), Screen Shots Jpeg (save only) Application Options Bias-Tee (On/Off), Impedance (50 , 75 , Other) Frequency Frequency Range 2 MHz to 4 GHz Frequency Accuracy ± 2.5 ppm @ 25 °C Frequency Resolution 1 kHz, (RF immunity low) 100 kHz, (RF immunity high) Output Power High 0 dBm, typical Low –30 dBm, typical Interference Immunity On-Channel +17 dBm @ > 1.0 MHz from carrier frequency On-Frequency 0 dBm within ± 10 kHz of the carrier frequency Measurement Speed Return Loss 1.00 msec/data point, RF immunity low, typical Distance-to-Fault 1.25 msec/data point, RF immunity low, typical Return Loss Measurement Range 0 to 60 dB Resolution 0.01 dB VSWR Measurement Range 1 to 65 Resolution 0.01 Cable Loss Measurement Range 0 to 30 dB Resolution 0.01 dB Distance-to-Fault Vertical Range Return Loss 0 to 60 dB Vertical Range VSWR 1 to 65 Fault Resolution (meters) (1.5 x 108 x vp)/F (vp = velocity propagation constant, F is F2-F1 in Hz) Horizontal Range (meters) 0 to (Data Points-1) x Fault Resolution, to a maximum of 1500 meters (4921 ft) 1-Port Phase Measurement Range –180° to +180° Resolution 0.01° Smith Chart Resolution 0.01 Measurement Accuracy Corrected Directivity > 42 dB, OSL Calibration > 38 dB, InstaCal™ Calibration For full Anritsu SIte Master S331E specifications, please click here: Anritsu Site Master S331E Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Sell Smarter with Kyozou. Inventory and Ecommerce Management

Condition:	Seller refurbished: The item has been restored to working order by the eBay seller or a third party. This means the item was inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See seller’s listing for full details. ...	Brand	Anritsu
Model	Site Master S331E
MPN	S331E
Type	Cable or Antenna Analyzer
