Apc Sua1000xl Smart-ups Xl 1000va 120v Usb And Serial Interface

US $1200

Valley Stream, New York, United States
Nov 13th

Open on mobile:
QR code

APC Smart-UPS XL 1000VA USB & Serial 120V Fully Tested. Guaranteed Not D.O.A. No Battery, SmartModule or any other accessories included. Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. Output Output power capacity 800Watts / 1.0 kVA Max Configurable Power (Watts) 800Watts / 1.0 kVA Nominal Output Voltage 120V Output Voltage Distortion Less than 5% at full load Output Frequency (sync to mains) 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal Topology Line Interactive Waveform type Sine wave Output Connections (8) NEMA 5-15R (Battery Backup) Input Nominal Input Voltage 120V Input frequency 50/60 Hz +/- 3 Hz (auto sensing) Input Connections NEMA 5-15P Cord Length 6ft ( 1.83meters ) Input voltage range for main operations 82 - 144V Input voltage adjustable range for mains operation 75 - 154V Number of Power Cords 1 Batteries & Runtime Battery type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Typical recharge time 2hour(s) Replacement Battery RBC7 Expected Battery Life (years) 3 - 5 RBC Quantity 0(No Battery's Included) Extendable Run Time 1 Battery Volt-Amp-Hour Capacity 408 Extended Run Options APC-Smart-UPS-XL-1000VA-USB-Serial-120V Runtime View Runtime Graph View Runtime Chart Efficiency View Efficiency Graph Communications & Management Interface Port(s) DB-9 RS-232 , SmartSlot , USB Control panel LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators Audible Alarm Alarm when on battery : distinctive low battery alarm : configurable delays Available SmartSlot™ Interface Quantity 1 Surge Protection and Filtering Surge energy rating 459Joules Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 Physical Maximum Height 8.5inches ( 216mm , 21.6cm ) Maximum Width 6.7inches ( 170mm , 17.0cm ) Maximum Depth 17.3inches ( 439mm , 43.9cm ) Net Weight 60.0lbs. ( 27.27kg ) Shipping weight 65.0lbs. ( 29.55kg ) Shipping Height 15.25inches ( 387mm , 38.7cm ) Shipping Width 12.6inches ( 320mm , 32.0cm ) Shipping Depth 23.25inches ( 591mm , 59.1cm ) Color Black Environmental Operating Environment 32 - 104 °F ( 0 - 40 °C ) Operating Relative Humidity 0 - 95 % Operating Elevation 0-10000ft ( 0-3000meters ) Storage Temperature -15 - 45 °C Storage Relative Humidity 0 - 95 % Storage Elevation 0-50000ft ( 0-15000meters ) Audible noise at 1 meter from surface of unit 42.0dBA Online thermal dissipation 120.0BTU/hr Conformance Approvals BSMI, CSA, FCC Part 15 Class A, UL 1778 Sustainable Offer Status RoHS Compliant PEP Available in Documentation tab EOLI Available in Documentation tab Other Environmental Compliance China RoHS
