Api Heat Exchanger Sx13-350-19 Heat Transfer

US $1,900.00

Watertown, Connecticut, United States
Jan 29th

Open on mobile:
QR code

Item Name: API Heat Exchanger SX13-350-19 Heat Transfer Item #: 9219 Price/Each: $1,900.00 Year: 2008 Brand Name: API Model: SA13-350-19 Serial #: NPO71079-101 Asset Tag: 5689 Item Location City: Watertown State: Connecticut Zip Code: 06787 Country: United States Item Description API Heat Exchanger SX13-350-19 Heat Transfer Model SX13-350-19 Dry weight 276 Lbs Hot MAWP 150 PSI @ 293° F Cold MAWP 150 PSI @ 293°F Hot MDMT 32°F @ 150 PSI Cold MDMT 32°F @ 150 PSI Serial number NPO71079-101 Year 2008 P/N 4-X13-GBE-019-007 Tightening dimension: 2508 Nom., 2470 Min Heat Transfer Surface Area-1.29 per plate, 19 plates total This unit can accommodate up to 30 plates total. Skidding/loading fee at time of sale From the manufaturer: Gasketed Plate Heat Exchangers SIGMA Plate Heat Exchangers utilize corrugated plates stacked between a fixed and a movable pressure plate. The corrugation patterns alternate for maximum operating pressures. As virtually all of the material is used for heat transfer, Plate Heat Exchangers can have large amounts of effective heat transfer surface in a small footprint. It is not uncommon that a Plate Heat Exchanger will have the same thermal capacity as a Shell & Tube five times larger. The unique corrugation pattern pressed onto each Schmidt thermal plate produces the highest overall heat transfer rate by assuring highly turbulent flow and excellent fluid distribution across the entire surface. With high heat transfer rates and true counter current flow, Schmidt Plate Heat Exchangers economically handle close temperature approach requirements. Operational Parameters Temperature: Pressure: Capacity: Connections: -40°F to 400°F Vacuum to 400 psig .5 to 8800 GPM 1" to 14" - NPT, Studded, Flanged, Tri-clamp, others Technical Data Plates: Standard AISI 304 (1.4301) AISI 316 L (1.4404) AISI 316 Ti (1.4571) Special AISI 904 L SMO 254 Nickel Alloys Titaniam, Titanium PD Thickness 0.4 mm to 1.15 mm Gaskets: Standard Nitrile, EPDM, EPDM-HT, Chloroprene Special H-NBR, NBR-HT, Viton, Butyle, PTFE coated (SIGMACOAT), gaskets approved for food applications Fixing Mechanically (SIGMAFIX) Glued on Frame: Painted Carbon Steel Stainless Steel Connections: Standard Nitrile, EPDM, AISI 316 Tk Special Nickel alloys, Titanium, Titanium-PD Codes: ASME, PED, ABS, LRS, GL, BV SIGMAFIX Mechanical Gasket API Heat Transfer's line of Schmidt Plate Heat Exchangers incorporate superior design features to ensure long term customer satisfaction. Highest quality gaskets precisely fit the plate grooves for positive sealing and ease of maintenance. Superior clip-on gasket design ensures proper fit during closing of the unit. Double sealing design prevents the possibility of mixing the two process fluids. Leak detect feature ensures any leakage is to the atmosphere. Zinc coated hardware provides long life. All plate pack tightening is done from the fixed pressure plate to eliminate any stud interference. All bolted construction for easier service. Low volumetric fluid hold-up provides quicker response to heating and cooling demands, while reducing costs for more expensive process fluids. Readily expanded for greater capacities, or totally new applications. SIGMA Plate and Frame Exchangers are available in a variety of plate sizes for industrial, HVAC or sanitary applications. Typical applications include: Chemical Pharmaceutical Food & Beverage Dairy Petrochemical / Offshore HVAC Marine Oil Cooling Breweries Surface Treatment Contact Us About This Machine Should you have questions, please contact 860-484-4449 PAYMENT & SHIPPING: Payment Details: We will email you an invoice for the full amount owed, including shipping. Please do not pay until you have received our invoice. Items not paid within 10 days from the end of auction, will be re-listed. Payments by check will be held for 4 days until check clears. Shipping Policy: We can ship LTL, Partial or Full, Van or Flatbed, Double Drop, and load into Containers for export! Freight costs to be quoted at time of sale. All freight costs to be paid by the purchaser prior to Pickup. Please contact the sales Rep above for a shipping quote. We usually ship within 5 business days of receipt of cleared payment. Freight shipments may take longer due to palletizing and scheduling. Items less than 100 lbs ship via UPS Ground. Freight may be booked with any carrier, but usually goes out on best available. If you need a lift gate please add $128.00 to your invoice. If your delivery location is residential, we will add $80.00 to the shipping charges. If a rigger is required please notify us prior to quoting shipping. Please email the sales rep for an accurate freight quote. If Buyer chooses to use their own freight, shipping account and or carrier, they will be responsible for all scheduling, paperwork, claims and any or all damages incurred in transit. Local Pickup is always welcome… No handling fees for Local Pickup. Any item not picked up within 30 days from End of Auction, will be charged 10% of items cost per month for storage. You are bidding on a used item. Please be sure to ask any or all questions prior to bidding. SOLD As Is/Where Is: The item being sold is being sold “as is” We will do our best to answer specific questions but please be aware that the equipment may no longer be located within the original facility and historical information and photos are very limited. Please be sure to ask any or all questions prior to bidding.
