Arbiter Systems 1093b Gps Time Atomic Master Clock Receiver Irig-b Timecode 1pps

US $200

Fairfax, Virginia, United States
Jan 29th

Open on mobile:
QR code

Arbiter Systems 1093B GPS Atomic Clock Time Receiver With Indoor Test Antenna • Very Good Condition • Latest Firmware (DST 2007 Compliant) • 110-240V AC Power Photos show the actual item for sale Introduction Here's a used GPS disciplined master clock unit with IRIG-B, Serial and 1 PPS outputs. The unit comes with power cord and a basic indoor antenna so it will acquire time for you right out of the box (when the antenna has a clear view of the sky when placed outdoors - indoor performance by a window is not guaranteed. I found the unit to be quick at obtaining the initial time with the supplied antenna placed outdoors with an unobstructed view of the sky. The included antenna is intended to get you started and to allow you to check out the unit the day it arrives. A weatherproof external antenna with a full view of the sky is recommended for a permanent installation and for achieving the highest level of time accuracy as the unit will need to track 8+ satellites to achieve this - and I usually have some listed that would be ideal. Alternatively you can choose your own antenna as any 5V L1 antenna should work well. I do have some antenna pole mounting skirts available which may solve the problem of how to mount a conical outdoor antenna in a robust weatherproof fashion. The firmware has been upgraded to the latest factory-supplied code so you're running the latest spec and won't have to worry about compliance with the 2007 DST changes. Note that no rack ears are included. Description The Arbiter Systems Inc. Model 1093B GPS Satellite-Controlled Clock is a GPS timing source for applications requiring an accurate time source with a better than 500ns accuracy. The Model 1093B features an LCD setup/status display and a keyboard for ease of inspection, configuration and operation. Two pluggable terminal strip outputs provide unmodulated IRIG-B and 1 PPS. These outputs have substantial drive capability to easily drive multiple loads in parallel. These outputs are configurable to provide other output signals or an event-capture input. Full details may be obtained from the User Manual. The power supply requirements are universal, accepting 85 to 264 VAC or 110 to 350 VDC connected by a standard IEC-320 inlet on the rear panel. Specifications Receiver Characteristics: Timing Accuracy: Specifications apply at the 1 PPS output, in the presence of Selective Availability (SA), as of date of publication. UTC/USNO: ±500ns peak Position Accuracy: 10 meters, rms, 90% confidence Satellite Tracking: Twelve (12) channel, C/A code (1575.42 MHz). Receiver simultaneously tracks up to twelve satellites. Results from all tracked satellites are averaged in Position-Hold Mode or, with Position-Hold Mode off, using least-squares estimation. Acquisition: 150 seconds typical, cold start 15 minutes, 90% confidence, cold start 40 seconds, with almanac less than 1 month old 15 seconds, with ephemeris less than 4 hours old I/O Configuration: Connectors: Two standard: one IRIG-B Unmodulated and one 1 PPS; Type: bus driver, 5 V CMOS; 10 ohms source impedance; ±75 mA drive capability; pluggable terminal strip. Programmable Pulse Output: One programmable output pulse (by a jumper connection) that may be output on a terminal strip connector or the AUX OUT pin on either RS-232 Port. Four modes: Every 1 to 60,000 seconds, starts top of the minute Hourly at a specified offset Daily at a specified time of day One shot at a specified time of year Pulse duration is programmable from 0.01 to 600 seconds, except in one-shot mode, where the output is Low prior to the specified time and High thereafter. Interface: Operator: Display: Status LEDs 2 x 20 character supertwist LCD Functions: Time: UTC or local Position: latitude, longitude, altitude Receiver and clock status 1 PPS (input) deviation Event time Status LEDs: Operate (green) Unlocked (red) Keypad: Eight keys; select display functions or setup menus Setup: Local time offset Output code select: Local/UTC Daylight Saving Time (Set Summer Time): Off/On/Auto USA/Auto EUR/Auto CUS Backlight control: On/Off/Auto Event input: Event/1 PPS Programmable Pulse setup Antenna delay Out of lock time: 1 to 99 minute(s), Off, or Zero Delay Auto-Survey: On/Off, Survey duration Position Hold: On/Off, Position Auto/Manual Option Configuration and Setup Serial port: RS-232 System: RS-232: 1200 to 19,200 baud; 7 or 8 data bits; 1 or 2 stop bits; even/odd/no parity Interrogate mode Broadcast modes: Standard ASCII (IRIG-J) Extended ASCII ASCII with Time Quality ASCII with Time Quality and Year Vorne large-display time Status/Alarm Event data Connector: Male 9-pin D-sub (TXD, RXD, AUX IN, AUX OUT) AUX OUT can provide programmable pulse function at RS-232 levels Power Requirements: Standard: Voltage: 85 to 264 Vac, 47 to 440 Hz, 20 VA maximum or 110 to 350 Vdc, 15 W maximum General: Physical: Size: 1 RU rack mount or tabletop, 260 mm deep FMS, Rack mounts included. 508 x 381 x 203 mm (20 x 15 x 8 in.), shipping Weight: 2 kg (4.5 lbs), net 5.5 kg (12 lbs), shipping Antenna: Cable Connection: F-type Environmental: Operating Temperature: 0° to +50° C (-20° to +70° C typical) Nonoperating Temperature: -40° to +75° C Humidity: Noncondensing EMC: Radiated susceptibility: passes walkie-talkie test. Conducted emissions: power supply complies with FCC 20780, Class A and VDE 0871/6.78 Class A. Surge withstand capability (SWC), power inlet: designed to meet ANSI/IEEE C37.90-1 and IEC 801-4 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Used, in good condition and fully working. The photos show the actual item for sale. No unpictured cables, accessories or documents are included.”
