Arduino Kit 40x2 Samsung Character Lcd Display + Keboard W/ Ir Usb Pushbtn Leds

US $150

Atlit, Israel
Feb 20th

Open on mobile:
QR code

BIDDING You are bidding on Character LCD Display Module + Keboard with IR(InfraRed), USB, PUSH BUTTON And LEDS LCD Made By: SAMSUMG Screen Size: 40x2 Character Chip On board: UC-40206 (HD44780 COMPATIBLE - ARDUINO COMPATIBLE) Pin Configuration: 2 * 7 Row Header(2mm/ 0.079") Pin Out: Pin Number Pin Assignemnt 1 GND 2 Vcc(+5Vdc) 3 Vo(Brightness max 5V) 4 RS 5 R/W 6 Enable 7 D0 8 D1 9 D2 10 D3 11 D4 12 D5 13 D6 14 D7 VERY EASY ARDUINO / MICROCONTROLLERS INTEGRATION! Integration Tutorial on Arduino: http://arduino.cc/en/Tutorial/LiquidCrystal Don't hesitate contact us for help with this prduct! full product service! Keyoard from DVR unit Information: we don't have an electrical scheme, but we know the pinout and connections. Keyboard has Infrared Reciver , 3.5mm Audio Input , USB connetion breaked-out on board , 13*Push Button , 5*Blue Leds PCB has 3* 74HC164(Serial in/Paralel Out) - To control leds and detect button clicks(complex) Don't hesitate contact us for more information! for bigger quantities - mail us for more information Sold as is See pictures My Policies: If for any reason, you are not satisfied with your purchase please contact us immediately by Email or Phone, before contacting eBay Resolution center or Leaving Feedback ! If the item describe "as is", there will be no returns unless it is "not as describe" issue. The main title dose not necessarily describe the item. If you are satisfied with your purchase please leave us a positive feedback ! Feel free to contact me via e-mail for questions or for additional photos. All e-mails will be answered as soon as possible ! PAYMENT PayPal Payment is accepted. INTERNATIONAL BIDDERS International bidders are always welcome. Taxes and customs duties are the responsibility of the international buyer. NOTE for Israeli buyers: The price does not include V.A.T. Please contact us for shipping + V.A.T. SHIPPING Shipping options: Registered, EMS, UPS, FedEx, DHL Buyer will pay actual postage charges. Your purchase will be carefully packaged for shipping using bubble wrap and/or shipping peanuts for fragile items. I cannot be responsible for uninsured packages that got lost or damaged during shipping. There is NO extra charge for packing materials or "handling" unless specified in the item description above. For the safety of the enviorment - We are using recycled materials for packing. Please let us know if you prefers new packing materials and we will charge you respectively. SHIPPING TIME We will ship the item within up to 3 business days after receiving the payment from the buyer. Register - Buyer usually receive the item within 11-23 business days. EMS - Buyer usually receive the item within 4-8 business days. UPS, FedEx, DHL - Buyer usually receive the item within 2-4 business days. It all depends on the Post office and custom. If you haven't receive your item within 30 business days after making the payment please contact us immediately. Please feel free to contact us any time with any question ! Thank you for your purchase ! Have a great day ! Part2Go Team TBD Powered by SixBit's eCommerce Solution
