Arm Ds203 Dso203 Nano V2 / Quad Pocket Digital-oscilloscope With Plastic Case

US $1700

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

Attention: The photos are for your reference only. Product Introduction ARM DSO Quad Pocket Digital-Oscilloscope (We do wholesale, please inquire us (info#surenoo.com) for the detail.) Tips: This pocket oscilloscope is primarily used for applications in the following situations: 1. Repair common electronic equipment outside (Air conditioning or Industrial frequency inverter power supply, AC / DC switching power supply or inverter, elevator and building fire safety equipment, industrial control circuit) 2. Hardware maintenance or software debugging RS232, RS485, I2C, CAN and other communications interface circuits, LED display and keyboard scan driver circuit, brushless motor drive circuit 3. Audio equipment and circuits, electronic toys and remote control models, car repair electronic circuits 4. School after-school teaching practice and student development of electronic small production 5. Need to slow signal changes observed applications (such as: relay and switch contacts jitter, battery charge and discharge curves of the load transient response power supply, temperature sensor features measurement) 6. The related supply t electronic circuit (SCR voltage regulator, power factor correction, electronic energy saving lamps, dysprosium lamp mercury lamp sodium lamp xenon lights drive circuit), As for other issues such as: CPU clock, RAM access, bus and USB or Ethernet signal measurement, high frequency and the video circuitry and the need to use FFT for signal analysis and so on occasion, The oscilloscope valued less than $1000 are not necessarily qualified for these. We advice to buy high-end oscilloscope! Deserves special mention is this pocket-sized internal battery-powered oscilloscope can be used, so in the field measurement, Ground is completely suspended, can be completely the same as multimeters, which measure what point, do not consider the issue of ground isolation. Important Note about the ePacket Delivery to US Buyer Due to ePacket Delivery refuse to ship with Battery, if you buy this item, we'll remove Battery out, and then ship Battery via Singapore Post Airmail to you separately, You may receive the Battery later than DSO Quad, when you get DSO Quad in advance, you can use USB Connect Power to use it, Thanks for your understanding & supports. Shipping about this item to US: 1. DSO Quad (without Battery) with other Accessory: ePacket Delivery to US (7-15 working days). 2. Battery: Singapore Post International Flat Shipping to US (10-20 working days). DOWNLOAD DSO203 is a pocket size 4 channel digital oscilloscope for common electronic engineering tasks. It's based on ARM cortex M3 (STM32VCT6), providing 72MS/s sampling rate with integrated FPGA and high speed ADC. Internal 2MB USB disk could be used to store waveform, user application and upgrade firmware. Feature 1) 2 probe connectors 2) 4 inputs & 4 tracks (2 analog 2 digital) 3) A custom waveform output (including the built-in sine, square, triangle) 4) Built-in 2M USB disk 5) Very low power consumption 6) Manual Specification Analog channel * 2 [CH_A] [CH_B] Digital channel * 2 [CH_C] [CH_D] Vertical Scale 50mV-10V/div (1-2-5 step) on x1 probe / 500mV -100V/div (1-2-5 step) on X10 probe Vertical resolution 8 bit Input coupling AC/DC Max input voltage 80Vpp (x1 probe) / 400Vpp (x10 probe) Storage 4K per channel / 8K on single channel Software trigger type edge, pulse, level (to be added) Hardware trigger type edge Trigger source CH1/CH2/EXT Trigger mode Auto, Normal, Single, SCAN, None Test Signal generater 10Hz to 8Mhz 2.8Vpp Square Wave, duty circle 10~90% adjustable / 10Hz to 20Khz 2.8Vpp Sin, Square, Saw, Triangle wave Storage internal 2MB USB disk, BMP, DAT file Auto measure Vmax, Vmin, Vpp, Vavr, Vrms, Freq, Period, Pulse, Duty Cursor measurement Level, Voltage Display mode CH1, CH2, EXT, CH1+CH2, CH1-CH2, CH1*CH2 Sampling mode real time Sampling rate 30S/s - 72MS/s Power Lipo battery Dimension 98 * 60 * 14.5 (mm) Weight 80g (without battery) Accessories within Pack 2 mcx osilloscope probe Cautions The warnings and wrong operations possible cause dangerous. Description ?3" 240 x 400 widescreen color TFT LCD screen, STM32 is the master MCU, with the FPGA to implement the control and management of external ADC and data cache. ?At the same time to reduce the size and easy to DIY manual welding, MCU and the FPGA are selected QFP100 package, ADC selected QFP48 package. ?36M+36M sampling frequency, the use of the ADC AD9288-40 chip, single-channel maximum sampling frequency of the 72M. ?FIFO RAM has a maximum operating frequency of use of> 200MHz low-power FPGA to achieve. ?The AD9288-40 Overclocking to achieve 72M+72M sampling frequency, so that the maximum single-channel sampling rate up to 144M. ?Analog channel circuit using unity gain> 150MHz op amp, so the actual 30MHz analog bandwidth is expected to do more. ?As low power, low-cost, QFP package and other conditions of the FPGA, storage capacity is not large, so DSO203 sampling depth of the current situation for the multi-channel 4096 points per channel, single-channel work cases, 8192 points. Frequently Asked Questions Q: If this is a beta run, will the device be firmware upgradeable (via USB) when and if bugs are found? A: Sure, just copy the firmware onto internal USB disk, press ">" while booting up to upgrade. Q: What are the user applications? A: [No official answer] As far as I know, there will be the possibility to boot up different applications that you can store on the U-Disk. I'll add a section to this page collecting ideas for user applications. Q: What is the battery life? A: It's 1000mAH, 3.7V More & more Questions & Answer are adding…… Certification CE Certification FCC Certification Packing List - ARM Digital Oscilloscope (DSO203) (Build-in Battery) x1 - Probe x2 - Mini USB Cable x1 Note: The foothold is not including in the package. Terms & Conditions Sales Terms & Conditions Please contact with us in English only, we are sorry for the inconvenience caused to you, thank you! Payment Terms & Conditions We can accept PayPal on eBay selling, please settle payment within 2 days after the auction ends, if you have any difficulty regarding payment, please contact with us ASAP. Feedback & Case/Dispute When you get the item you bought, if you satisfied with it and our service, please leave us Positive Feedback & 5 Star DSR to us. If you have any problem, please contact with us in advance. We can give you response within 24 hours when we get your message, we'll try our best to give you the better solution. Please don't open Case / Dispute or leave Negative / Neutral to us directly, or you'll assume the responsibility/result. Shipping / Postage Terms & Conditions Carrier: China / Hong Kong / Singapore / Swiss / Sweden / Netherlands / Belgium Post (ship to all over the world except US) US: It's required to add extra shipping cost than other country via ePacket Delivery (eBay Policy) from China with tracking number (7-15 business days). Shipping Detail Shipping Method International Flat Shipping (Economy Int'l Shipping) Registered Air Mail (Standard Int'l Shipping) FedEx/DHL/UPS/TNT/EMS Delivery Time 10-20 Working Days 10-20 Working Days 3-7 Working Days Shipping Tracking Without Tracking Number Registered Airmail Parcel / Note: 1. If you have selected "Economy Int'l Shipping" with extra Registered Charge, you'll get the tracking number on the eBay transaction as the following example image in about 1-2 working days after your payment: 2. All the tracking number can be tracked in the following website (http://www.17track.net/index_en.shtml) in about 2-3 working days later after we ship out. Please allow 10-20 working days (depends on where you are) for delivery, because all item will be shipped from our our warehouse in China via Air Mail. The item will be posted to you within 1-2 working day generally after the payment is cleared on seller's side. All the fee & tax in oversea must be paid by buyer. Return & Replacement Terms & Conditions Postage is not returnable. We will refund you the price of the item less postage. Seller is not responsible for the postage of returning items. Buyer can return the item in the original package within 7 days upon receiving if you are not happy with it/ We will refund you or send replacement to you within 3 working day after the item is received. Welcome to visit our store again.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Surenoo Technology
Sample Rate	Less than 200MSa/s
Model	DSO203
Country/Region of Manufacture	China
Type	Digital
Make	Surenoo Technology
Bandwidth	Less than 60MHz
Number of Channels	4
Channels	Over 4
Country of Manufacture	China
