Arpi600 Expansion Board For Connecting Raspberry Pi Model B+ With Xbee & Arduino

US $23.99

Shenzhen, Guangdong, China
Jan 29th

Open on mobile:
QR code

This auction is for ARPI600 Raspberry Pi Model B+ Expansion Board, Supports Arduino XBee Overview Arduino is a massive ecosystem, if there's a way for the Raspberry Pi GPIO interface to adapt to Arduino pinouts, it is possible to use the Pi together with vast Arduino shields and hardware/software resources. The ARPI600 is just intended for this. What's more, the ARPI600 also support XBee modules, make it easy to add wireless feature to your great project. ARPI600 Features Compatible with Arduino UNO, Leonardo, easy to connect with various Arduino shields XBee connector for connecting various XBee modules Sensor interface for connecting various sensors Onboard USB TO UART for serial port debugging, also can be configured as XBee USB adapter Onboard ADC, 10 bit, 38KSPS, 11 channels (6 channels for Arduino interface, 5 channels for sensors) Onboard RTC What's on the ARPI600 Arduino connector : for connecting Arduino shields ICSP interface : Arduino ICSP XBee connector : for connecting XBee communication modules Sensor interface : for connecting sensors Raspberry Pi connector : for connecting Raspberry Pi USB TO UART TLC1543 : AD converter PCF8563 : RTC CP2102 32.768KHz crystal : for RTC Power indicator XBee state LED XBee and Arduino interface RESET button XBee EASYLINK button RTC battery holder : for CR1220 button battery TLC1543 reference voltage configuration jumper RTC jumper UART jumper when connecting P_RX and CP_TX, P_TX and CP_RX respectively, USB TO UART is connected to Raspberry Pi serial port when connecting XB_RX and CP_TX, XB_TX and CP_RX respectively, USB TO UART is connected to XBee serial port when connecting XB_RX and P_TX, XB_TX and P_RX respectively, Raspberry Pi serial port is connected to XBee serial port Arduino AD selection jumper short 2 and 3 : Arduino A0-A5 as AD input short 1 and 2 : Arduino A0-A5 as digital control Arduino I2C selection jumper short the jumper : Arduino A4-A5 as I2C control (the A4-A5 of Arduino AD selection jumper should be opened) Arduino SPI selection jumper short 1 and 2 : Arduino D11-D13 as SPI control (default) short 2 and 3 : Arduino D11-D13 as digital control ARPI600 Photos ARPI600 Raspberry Pi Model B+ Expansion Board ARPI600 Raspberry Pi Model B+ Expansion Board back view Connecting with Raspberry Pi Model B+ Connecting with Raspberry Pi and XBee Connecting with Raspberry Pi and GSM/GPRS Shield Connecting with Motor Control Shield Connecting with Motor Control Shield and XBee Connecting with Arduino IO Expansion Shield and sensors ARPI600 Dimension Package Contains ARPI600 x 1 USB type A plug to mini-B plug cable x 1 RPi screws pack (2pcs) x 1 1 2 3 Downloads Development resources: demo codes, schematic, datasheets, etc. Click here to download Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Country/Region of Manufacture	China
Model	ARPI600
Supports	Raspberry Pi Model B+ and Arduino XBee
