Arrow Hart Gray Twist Turn Locking Flanged Outlet Nema L10-20r 20a 125/250v 6246

US $16.99

Jamestown, New York, United States
Jan 29th

Open on mobile:
QR code

Fruit Ridge Tools, LLC Our eBay Store Contact Us Add to Favorite Sellers Arrow Hart Gray Twist Turn Locking Flanged Outlet NEMA L10-20R 20A 125/250V 6246 Product Details Quantity in Lot: 1 Brand: Arrow Hart Part Number: 6246 Color: Gray Type: Locking Flanged Outlet Phase (if applicable) : Single Phase Poles: 3 Wires: 3 NEMA Number: L10-20R Amperage: 20A Voltage: 125/250V Grade: Industrial Specification Grade Ground: Non-Grounding Arrow Hart 6246 gray locking flanged outlet. Industrial Specification Grade, NEMA L10-20R, 3-pole, 3-wire, non-grounding, rated 20A 125/250V. Terminals accommodate #18-#10 AWG. Each is individually packaged; packaging may differ from photo. Features include:One-piece, rivetless, .035" thick brass contacts offer enlarged contact surface area, low heat, and long life Cleat on contacts cuts oxidation when plug blade enters contact surfaceInternal wiring chambers isolate individual conductors to prevent flashover, arcing, and stray strands of wire Deep-funnelled, large rectangular-shaped chamfered wire wells guide conductors into termination position Transparent wiring chambers provide a means of visual inspection of conductors and terminals Wire clamps move within individual chambers to provide positive crimp lock without cutting wire strands Color-coded terminal screws Molded-in strip gage provides correct measurement for proper strip length of conductorCaptive terminal screws eliminate nuisance dropping and searching for missing screws Positive crimp contact plate bundles stranded wire maximizing wire/clamp surface contact Combination #10-32 deep slotted/ Phillips brass screws easily torque to 10-14 in.-lbs. Super tough nylon body resists damage from severe impact, abrasion, and chemical attack NEMA configuration, agency certifications, and device rating are molded on front of device to assist with identification This is New Old Stock and is returnable for any reason. (SKU # AH6246-EA; Weight: 0.40 lbs.) Need Wallplates? 15A Wallplates (1.406" Diameter) 20A & 30A Wallplates (1.60" Diameter) Additional locking devices and information: Matching L10-20R Plugs, Connectors & Receptacles See All Straight Blade Plugs, Receptacles and Connectors See All Locking Plugs, Receptacles and Connectors

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Arrow Hart
MPN	6246
