Asco J-series Tri-point Sealed Miniature Deadband Pressure Switch With 1/4” Npt

US $24.00

Medford, Massachusetts, United States
Jan 29th

Open on mobile:
QR code

ASCO J Series Miniature Pressure Switch XJC38A218C15297 (NIB) ASCO J-SERIES Tri-point sealed miniature deadband pressure switch with 1/4” NPT male thread Catalog #: XJC38A218C15297 Box Label: XJC38A218C15297 C88448P B9 SPECS factory stamped band reads: 88448P cat #: XJC38A218C15297 set points: 85-100 circuitry: SPDT PSIG: 5.8-7.0 ELECTRICAL factory label reads: 5 Amps RES @ 125 or 250 VAC 3 Amps RES @ 28VDC Includes factory’s paper copy of the datasheet (shown.) Weight: 8 Oz. About J-Series... Features: • Tamperproof, factory-set, non-adjustable set points. • Fixed deadband. • Environmentally sealed against dust, water, oil and salt spray, e.g., for off-highway equipment. • Vented construction for stable set points throughout operating range. • Vibration and shock resistant to 10 G’s. • Precision electrical snap-action switch. General Description: J-Series miniature pressure switches have factory-set non-adjustable set points and fixed deadband, with diaphragm piston sensor. J-Series switches are CSA approved and UL listed under “Industrial Control Equipment”. J-Series switches are sealed with specially compounded epoxy that maintains its sealing integrity from -40 to 250°F. Proof pressure: 250 psig. (Consult factory for higher pressures). Process connection: Standard: 1/8” NPT Ext, 1/8” NPT Int, 1/4” NPT Ext. Optional: 1/4” NPT Int (eighth digit “3”). Standard Electrical Ratings Low-Cost Switches with Non-Adjustable Set Points 5 Amp Res., 125 VAC 5 Amp Res., 250 VAC 3 Amp Res., 28 VDC Standard Temperature Ratings Ambient: -4°F (-20°C) to 140°F (60°C) Fluid: -4°F (-20°C) to 180°F (82°C) Wetted Materials (Process Connection & Diaphragm) Standard: Brass and Buna “N” Optional Process Connections: • 316 SS (sixth digit “4”) • Carbon steel (sixth digit “6”) Optional Diaphragms: • Viton (seventh digit “2”) • Neoprene (seventh digit “3”) • Ethylene propylene (seventh digit “6”) • Fluorosilicone (seventh digit “7”) Check out my other items!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Asco
MPN	Asco - Pressure Switch - Catalog #J838A215C
Model	Asco - Pressure Switch - Catalog #J838A215C
Country of Manufacture	United States
