Assembled Dso150 Digital Oscilloscope 2.4" Tft Lcd Display W/ Clip + Power Plug

US $45.41

Shenzhen, China
Jul 17th

Open on mobile:
QR code

Product Description Assembled DSO150 Digital Oscilloscope 2.4 inch TFT LCD Display with Clip + Power plug + BNC Clip Cable Probe Features: • Adopts ARM Cortex-M3 processor (STM32F103C8), and includes a 2.4-inch color TFT display screen • Used for secondary development on the basis of this kit, for example, it can be changed to millivoltmeter, data loggers *Has automatic, conventional and single trigger mode, convenient to capture the instantaneous waveform • Come with instructions, easy to install and operate • Auto/normal/single trigger modes, easy to capture the moment waveform • Available rising or falling edge trigger • Observable previous waveform before trigger (negative delay) • Can freeze waveform display at any time (HOLD function) • Waveform parameter digital display, including frequency, period, pulse width, duty ratio, MAX./MIN./AVG./Peak-Peak/virtual values • Waveform storage function: Will not lose the waveform after powering off • Short-circuit and open-circuit detection: Can help the user find out the soldering error • TFT controller recognition function • The SMD has been soldered, more suitable for electronic beginners • Test signal source with 1KHz /3.3V square wave • Save/tune out the waveform, the shutdown waveform does not disappear • 100 brand new and high quality Specifications: *2.4-inch color TFT LCD with 320 x 240 resolution *Maximum Real Time Sampling Rate: 1Msps *Precision: 12Bit *Sampling Buffer Depth: 1024 bytes *Number of Channel: 1 *Analog Band Width: 0~200KHz *Vertical Sensitivity: 5mV/Div~20V/Div (progressive by 1-2-5) *Trigger Position: 1/2 of buffer size fixed *Sensitivity Error: < 5% *Input Impedance: 1M Omega *Supply Current: 120mA *Maximum Input Voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe) span style="font-size:14px;">*Coupling Methods: DC/AC/GND *Horizontal Time Base Range: 10 s/Div~50s/Div (progressive by 1-2-5) *Maximum input voltage: 50 Vpk (1X probe) *Input impedance: 1M ohms/20pF *Record length: 1024 points *Time Base Range: 500s/Div – 10us / Div *Trigger modes: Auto, normal, and single *Trigger position: Center of buffer *Supply voltage: DC 9 V (8 – 10 V) *Current consumption: ~120 mA @ 9 V Package List: 1 x Oscilloscope 1 x BNC Clip Cable 1 x Probe 1 x Power adapter 1 x User manual Note: this Oscilloscope without battery in it,must connect with the power adapter. Payment Delivery details Return About us Contact us Payment We accept Payment via PayPal only. If you do not have a PayPal Account you can still pay with your Credit / Debit Card, but this will be through PayPal ONLY. VAT and TAX is not included, please not. Delivery details Will ship order within 1 working days after get your payment. We do NOT accept any Email/Message note before or after you place orders. If item price is over $15, we'll ship with tracking number. Or it depends(except US). Shipping to US,AU,UK and CA takes about 7-15 working days for delivery normally. Standard shipping to other countries is about 7-25 working days. If remote countries, like Peru, Chile,Brazil and so on, it takes about 25-45 working days for delivery normally.Economy shipping takes about 10 working days more than standard shipping. shipping is out of control. Sometime shipping may take longer time. Hope you can wait some more days. If item did not arrive before Estimated date, pls contact us. We can refund or resend first, don't worry. Don't leave a negative feedback before contact us. Thank you very much. Return We understand that not every purchase is a good one for every custome Please note that we only accept returns within 30 days after delivery. If the item is defective/DOA (Dead on Arrival) we must be notified within 2 days of arrival, and a refund in full will be granted after item is sent back. Returns after 30 days will not be accepted. Please allow up to 3 business days for your item to be inspected and your return to be be processed. About us We will make every effort to make your shopping the most pleasant and wonderful! Any question feel free to contact us! Please do not leave negative and neutral rating , if you have any questions , please contact us . We will do best to solve it. Contact us We'll reply your message within 24 hours on working day because of jet lag. If Weekends or holidays, we'll reply within 48 hours. Will do best to solve problem. Please trust us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	WU0927MG-97
Trigger modes	Auto, normal, and single
Number of Channel	1
Maximum Real Time Sampling Rate	1Msps
Sensitivity Error	< 5%
Analog Band Width	0~200KHz
Coupling Methods	DC/AC/GND
Input Impedance	1M Omega
Record length	1024 points
Horizontal Time Base Range	10 s/Div~50s/Div (progressive by 1-2-5)
Supply voltage	DC 9 V (8 – 10 V)
Time Base Range	500s/Div – 10us / Div
Brand	Unbranded
Current consumption	~120 mA @ 9 V
Precision	12Bit
Country/Region of Manufacture	China
Vertical Sensitivity	5mV/Div~20V/Div (progressive by 1-2-5)
Sampling Buffer Depth	1024 bytes
Supply Current	120mA
Trigger Position	1/2 of buffer size fixed
Maximum input voltage	50 Vpk (1X probe)
UPC	6973691285008
