Assembled Xr2206 Function Generator Diy Kit 20hz - 100khz

US $35.00

Jerusalem, israel, Israel
Jan 29th

Open on mobile:
QR code

Assembled Soldered Function Generator XR2206 DIY Kit 20Hz - 100KHz Tested and Calibrated! DIY Electronic Kit based on XR2206 IC. Simple to assemble kit with English PDF Manual. Excellent for hobby home use. The DC level at the output is approximately the same as the DC bias. Please use external capacitor to cut the DC in the output! XR2206 Function Generator Kit is produce high quality Sine and Triangle wave outputs with high stability and accuracy. Square wave output is open collector type and buffer stage for square waves are recommended. The frequency range is selected with jumper on the PCB or you can connect external 1 Pole 4 Position Rotary Switch to the pins on the PCB board. Technical Specification: Frequency: 20Hz to 100KHz in 4 ranges with fine adjust Waveforms: Sine, Triangle, Square Supply Voltage: 12V Supply Current: 12-20mA PCB Dimensions: 73 x 38 mm Sine Wave: Amplitude: 0.05 - 2V AC Peak to Peak at 12V DC Distortion without adjustment: 2.5% Distortion with adjustment: less than 1% Output Impedance: 600 Ohm Amplitude Stability: 0.5 dB Triangle Wave: Amplitude: 0.05 - 4V AC Peak to Peak at 12V Linearity: 1% Output Impedance: 600 Ohm Square Wave: Amplitude: 11V AC Peak to Peak at 12V non-adjustable Rise time: 250 ns at 1 KHz Fall time: 50 ns at 1 KHz Take note, the square waveforms amplitude can not be adjusted with on-board pots, because of internal XR2206 IC peculiar properties. The square wave output is "Open Collector" type with pull up resistor. XR2206 Circuit and Explain Download USER MANUAL PDF Short demonstration video: External Switches and Buttons is not included in the package! Package include: 1x Assembled Soldered XR2206 Function Generator board To our valued customers, please read purchase terms before you bid or buy! Technical issues and support: If you purchase this item you are agree that you have skills and tools to perform required DIY soldering (or de-soldering) and you know how to connect additional external components or modules. All project components should be installed and soldered in proper polarity with proper connectors. Any hardware/software modifications are not covered with warranty. If you have doubt it always better to ask for technical support before doing something. Please download and read carefully PDF user manual, product purchase terms. Almost all technical issues already described in the manual! If you have any technical issue with the product please contact us asap. Support provided by email or via eBay message. Please read support requirements here http://www.rhelectronics.net/store/support-request Please read carefully product title, description and include list. Any questions are welcome. If you received broken or defective parts please contact us first, because we can resolve this problem in best way. Handling time: 3 business days to process international orders required after receiving cleared payment. This does not include the number of business days the shipping service will take to deliver the item to you. We can upload a tracking number during handing time even before your package was transferred to logistic company for the delivery. Shipping: We dispatch your order during 1-3 business day and will upload a tracking number to eBay for USA buyers only. Take note, international shipping is more complicated and longer than domestic, that's why when you buy internationally it mean you are agree to wait for the package. For Economy International Delivery default stated time is 3-5 weeks. Some countries may take longer because of your country custom regulation rules or postal service. USA usually take 2-4 weeks; Europe 1-4 weeks; Australia 2-4 weeks; Germany 3-4 weeks; Israel 3-7 days; Russian Federation 4-8 weeks; All other countries 3-5 weeks default delivery time. Please contact us if you not received your package during 30 days. During checkout you can select available and preferred shipping method for you country. We offer Economy International Shipping and Priority International Express Delivery. If you cannot wait 30-35 days for the delivery please select faster and more expensive method in advance! We do not accept any claims for shipping time if you have chosen Economy Shipping! Economy Shipping mean we'll send your items with Registered Air Mail, but we cannot promise it will be fast, because it depends on post service, flights schedules, weather accidents, custom processing and other things that out of our control. Priority Express Delivery promise you'll receive the order much more faster, so make your decision about shipping method before you pay. Priority Mail available for USA, United Kingdom, Canada, Germany, Australia. Other countries can select EMS Express. Tracking: Take note, we ship through state export account and not from post office branch. This is the reason why your package is trackable only after it was sent abroad from Israel export and not at the date of collecting or at the date we uploaded a tracking number. Online tracking system in Israel displays information with big delays, post website provide tracking info for reference only several days after your item was sent abroad! Please be patient for the delivery and contact us if you have additional questions about shipping. Don't buy/bid if you are not ready to wait for the package during 3-5 weeks when you select Economy Shipping! Don't buy/bid if you make low DSR feedback because of shipping time or shipping price or just because of your custom import tax! Custom & Duty Fee: All international buyers are responsible to cover any possible custom fee or import tax that maybe applied at his/her country. We are obligated by export law of Israel to declare an order price as it was stated in your PayPal bill. German buyers, please remember when you buy that in Germany import custom rules require you to pay fee. We are not accept any claim because of your country custom regulation rules / delays / fee! Please contact your local custom office for more details about custom process and import tax. Returns: Accepted if you not started to solder/use device. In original package, including all components. During 14 days after you receive the package. Payment: Paypal only, or cash for local pickup. 2013 Year RH Electronics Customers Location Thank you for your positive feedback!

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Manufacturer

radiohobbystore
