Assembly Manual And Tube Charts For Heathkit Tc-3 Tube Checker / Tester

US $12.45

  • Pickerington, Ohio, United States
  • Jan 29th
Open on mobile:
QR code
This is a bound printed documentation set for the Heathkit Tube Checker Model TC-3 emission tube tester. This is everything you would need to assemble, maintain, repair and use your TC-3 tube tester. Included is a new copy of the complete TC-3 Assembly Manual.  The TC-3 tester includes a socket for 7-pin sub-miniature (pencil) tubes.  Included is a one page supplement to test some of these tubes.   As for testing other tubes, I'm including test charts and supplements from TC-1 / TC-2 testers.  All of these charts work with the TC-3.  These copies are from vintage originals.  They are readily legible, but in some of the tube charts it's difficult to make out the plain font from the bold font.  The bold/plain fonts are used for the "short" test.  To overcome this problem, I'm also including a charts for the CTI TC-20.  This chart uses the same settings, but also includes compactron tubes that you won't be able to test with the TC-3. Please let me know if you have any questions. Thanks
Condition New other (see details) :
A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes “Comb bound, fresh reproduction printed copy.”
