Atlas Lcr40 Passive Component Analyzer

US $132.95

  • Santa Clara, California, United States
  • Jan 29th
Open on mobile:
QR code
The Atlas LCR40 is an advanced instrument that greatly simplifies the testing of passive components. Traditional LCR bridges are inherently complex and very time consuming to use. The Atlas LCR does everything automatically, it tells you the component type in addition to component value data. What's more, the Atlas LCR automatically selects the best signal level and frequency for the particular component under test. Just clip the universal test leads to your component and press the test button. In seconds, the Atlas LCR will identify the type of component (Inductor, Capacitor or Resistor) together with the component’s main value. Additionally, further component data is also displayed, such as the DC resistance of an inductor. The test frequency is automatically selected to suit the component under test and this is also confirmed on the scrollable display. The Atlas LCR is supplied with our new detachable micro-hooks, allowing the use of the optional SMT Tweezers, prods and chunky grabbers. See also out CRC01M and SMD03M parts for other connector types.  Supplied fully assembled, tested and aligned with a factory warrenty this is an indispensable piece of test equipment for a system designer or product technician. We use one in our store all the time to measure passive components. Alltronics Part# LCR40. Datasheet :  http://www.alltronics.com/mas_assets/acrobat/LCR40.pdf. Usage Video :  http://www.youtube.com/watch?v=gCQ3ACSwLOg
