ATTEN ATF20B DDS Function Generator(40mHz~20MHz), US $4600 – Picture 0
ATTEN ATF20B DDS Function Generator(40mHz~20MHz), US $4600 – Picture 0

Atten Atf20b Dds Function Generator(40mhz~20mhz)

US $4600

  • Littleton, Colorado, United States
  • Jun 15th
Open on mobile:
QR code
Excellent condition Fully tested and functional. This unit came from research LAB  with very little use. See Pictures for condition . Unit out put demonstrated on HP scope that is for sale on another listing. The ATF20B is running on Channel four of this scope.. Includes Power cord and  one BNC to BNC cable. NSTRUCTIONS ATF20B Function generator uses Direct Digital Synthesis (DDS)technology. Its outstanding performance and system features make it a perfect solution for your testing requirement. The simplified and optimized design of the front panel and dual-language (English/Chinese)TFT display interface make your testing much easier for operation and observation.  Additionally, the extendable optional functions can also improve your system characteristics. FEATURES Direct Digital Synthesis (DDS) technology, independent output channels High Frequency Resolution: full-range resolution is 40 MHz Store 40 sets of the user parameters and recall 32 kinds of standard or build-in fixed waveforms Minimum stable output waveform: 1mV(50) Multiple modulation functions: FM, FSK, ASK, PSK Frequency sweep, amplitude sweep and burst functions Count the frequency, period, amplitude RMS value or peak-to-peak value Over-voltage, over-current, output short-circuit and reverse voltage protections High reliability: use VLSI components and surface mount technology Power Amplifier: optional part, maximum output power up to 7W Optional configurations: RS232 interface, Frequency Counter, Power Amplifier GENERAL CHARACTERISTICS Power Supply: AC220V (1±10%) AC110V (1±10%) (Pay attention to the voltage selection on rear panel) Frequency:50Hz (1±5%) Power Consumption: < 45VA Operation Characteristics: Keypad operation and rotary knob operation Display: TFT display, 320*240 Weight: 3.5kg
