Audio Bi-amplifier, 100w W/ 2-way Linkwitz-riley Crossover - Electronic Kit

US $480

Livermore, California, United States
Jun 9th

Open on mobile:
QR code

Imagine audio so clear you can hear fingers hitting the frets, the breaths between the lines, and even the spit on the singer's lip. Converting your speakers to Bi-Amp mode is the single most powerful thing you can do to reach that kind of clarity. And this Bi-Amplifier can help you do that. On-board 2-way active crossover drives dual amplifiers for separate woofer and tweeter Linkwitz-Riley crossover, 4th order, 24dB/Octave roll-off Uses two LM4766 Chips in bridged configuration to produce 100W peak on both woofer and tweeter Great for Bi-Amp’d Active Speakers Crossover frequency configuration components are on a single socketed module - quick and easy to change the XO frequency by simply snapping in a new module. Wide range of standard XO frequency modules are offered by Xkitz, any frequency available on request Baffle Step Compensation, optional, adjustable and configurable to support various baffle sizes Supports unbalanced signal inputs by default, balanced audio signaling is available as an add-on option. Unbalanced signals are connected via standard RCA jacks Balanced signals are connected via optional 3.5mm TRS jacks. The TRS jacks are wired to be directly compatible with the new hi-def audio players such as the Pono Specifications: THD: 0.044% THD+N: 0.046% Frequency Response Linear from 20Hz – 80KHz CMRR (balanced input): > 55dB Input Impedance 30K ohms unbalanced, 60K balanced Input Overload: 3.8V peak-to-peak Voltage Gain: Adjustable, Max 29dB Filter Topology: Linkwitz-Riley, 4th Order Amplifier Type: Class AB Power supply: Single positive DC rail (no negative supply required) 22V–50V DC Applications: Speaker Bi-Amp conversions Bi-Amp’ed Active Speaker System Portable boom-box Portable guitar amplifier Custom speaker systems Channels are phase aligned to within a fraction of a degree to minimize distortion around the XO frequency Separate bass and treble output level adjustments via on-board multi-turn trim-pots Quiet power ON / power OFF Low power consumption and no negative supply needed - perfect for portable battery powered amplifiers This is a mono device, two units are needed for stereo operation PCB Dimensions: 3.4” x 3.6” x 2” High (86mm x 91mm x 51mm) This is an intermediate electronic kit containing 130 components, and can be assembled in about 2-3 hours Preview the Instruction Manual (.pdf)
