Auto-dip 3530 Dip Soldering Machine/mini Wave Solder Machine

US $7,995.00

San Diego, California, United States
Jan 30th

Open on mobile:
QR code

Auto-Dip 3530 Dip Soldering Machine The Auto-Dip 3530 is ideal for electronic assemblers looking for an easy and affordable way to improve soldering speed and consistency. Dramatically more efficient and reliable than hand soldering or manual dipping, the 3530 features a pin-type, fixture-less board holder for PCBs up to 350 x 300 mm (13.8" x 11.8"). Multiple boards as small as 60 x 60 mm (2.4" x 2.4") can be soldered simultaneously by simply placing as many on the holder as space allows. Independent dial-adjustable speed controls of the left and right elevator motors regulate dipping speed and angle. Pin-type, “bed-of-nails” PCB holder for boards from 60 x 60 mm (2.4" x 2.4") to 350 x 300 mm (13.8" x 11.8"); no special fixturing or pallets needed Multiple small boards can be processed simultaneously, provided they fit within the 350 x 300mm area; pin supports allow random placement of PCBs and assemblies in loading area Independent, dial-adjustable, speed controls for left and right elevator motors control dipping angle and speed to simulate wave soldering Digital timer for setting solder dwell time; typically 3-5 seconds Titanium solder pot; holds approx. 70 Kg (154 lbs.) lead-free SAC; approx. 85 Kg (187 lbs.) SnPb Digital PID solder pot temperature controller for lead-free SAC or SnPb solders Automatic dross skimmer and collection trough; cycles prior to dip soldering function Multi-day, 24-hr. timer for automatic startup; allows melting of solder and heating to desired solder bath temperature prior to production Foot pedal for hands-free actuation of soldering cycle Heavy-duty, steel mounting stand with levelers included; adjustable from 660-700 mm PCB handling tongs included for safe loading and unloading of boards Optional spray fluxer accessory available Auto-Dip 3530 Soldering System - Specifications PCB Size: 350 mm x 300 mm (13.8" x 11.8") max. 60 mm x 60 mm (2.4" x 2.4") min. Solder Pot Size: 400 mm W x 340 mm D x 80 mm H (15.75" x 13.4" x 3.15") Solder Pot Capacity: approx. 70 Kg (154 lbs.) Lead-Free SAC approx. 85 Kg (187 lbs.) SnPb Solder Pot Temperature: recommended 285 °C (545 °F) Lead-Free SAC recommended 265 °C (509 °F) SnPb 450 °C (842 °F) max. Solder Dwell Time: 1-10 sec. Preheat Time: 0-120 sec. Overall Dimensions: Auto-Dip 3530 600 mm W x 750 mm D x 540 mm H (23.6" x 29.5" x 21.3") Weight: Auto-Dip 3530 80 Kg (176 lbs.) Shipping Weight: approx. 125 Kg (275 lbs.) Power Requirements: 220V, Single Phase, 50/60 Hz, 32A, 3.6KW Contact Us: Eastern North America Sales Western North America Sales Business hours: 8:30AM - 6:00PM EST Business hours: 7:30AM - 5:00PM PST Tel: 215.830.1200 Tel: 858.490.6266 Fax: 215.830.1206 Fax: 858.581.0595 Toll Free: 800-PIK-MANN (800.745.6266) Toll Free: 888-PIK-MANN (888.745.6266) Direct Contact Any Time: Chris Ellis: (215) 869-8374 Jeff Mann: (619) 559-6266 Email: cellis@smt-auction.com Email: jmann@smt-auction.com Check out more dip soldering machine on Manncorp.com

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Brand

Manncorp
