Auto Transfer Switch Deep Sea Ats Controller Module Dse703

US $80.53

Shanghai, China
Jan 30th

Open on mobile:
QR code

AUTO TRANSFER SWITCH DEEP SEA ATS CONTROLLER MODULE DSE703 TIMING MACHINE MEASURE GAUGE MULTIFUNCTION TESTER TIMEGRAPHER NEW NO.1000 WATCH VERTICAL PNEUMATIC TAPPING MACHINE ARM 900MM COLLET M3-M12 MOTOR 38MM LARGE 5 TIERS PARTY HOTEL COMMERCIAL CHOCOLATE WATERFALL FOUNTAIN 26.5" 1PC NEW FANUC MEMBRANE OPERATOR KEYPAD A98L-0001-0568#M Introduction: The DSE703 is an Auto Transfer Switch Control Module that has been designed to monitor the mains (utility) supply. When the mains (utility) power fails the module sends a start request to the generator control unit. When the generator is up and running the module transfers the load across. When the mains (utility) returns the module transfers the load back and removes the start command. The generator should then begin it's shutdown procedure. The module can be configured so that they follow the users pre-set start and stop sequences. "Features: Manual start. LED indicators. Configurable timers. Front panel mounting. Configurable outputs. Load changeover control. Front panel programming. Single/three phase mains sensing. Protected solid state (PSS) outputs. Automatic mains (utility) supply monitoring. Benefits: Transfer's between mains and generator power On-site module configuration to match user requirements. Operation: The module is operated by the three push-buttons on the front: Manual Off Load - This is used to manually start and run the engine off load. Should the mains (utility) supply fail, then the load is transferred to the generator automatically. Manual On Load- This mode is used to manually start and run the engine on load. Auto Mode - This puts the module into automatic mode, where it will await a mains failure. Upon detection it will send a start request to the generator control unit. The DSE702 is a Manual/Auto Start Control Module that offers an excellent range of engine monitoring and protection features. The module has been designed to monitor low oil pressure, high engine temperature, over speed and a user defined auxiliary input. It also has the capability to monitor battery charging by utilizing the WL terminal on the charge alternator. When the module detects a fault condition it automatically shuts down the engine. The module also includes a tamper proof engine hours counter and a a remote start signal input. The input allows the module to be started from a pre-defined remote location. Main Features Manual start: Remote start. LED indicators. Engine pre-heat. Front panel mounting. Tamper proof engine hours counter. Protected solid state (PSS) outputs. Engine monitoring and protection features. Benefits: Multiple engine parameters are monitored simultaneously. Hours counter provides accurate information for monitoring maintenance and warranty periods. Operation Manual Mode: The user turns the key to the hand position. The start button is then pressed to start the engine. The module is started using the on-board key/buttons. The engine pre-heat button is then pressed for the required time. To stop the engine the key needs to be turned to the off position. Automatic Mode: The module is powered up by the remote start signal. The key needs to be permanently left in the hand position. To stop the engine the remote switch is turned to the off position. The pre-heat function is automatically carried out and then the engine is started. lkgp uwhu kbwl UAC Buyer should pay within 7 days after purchase. We only accept payment via PayPal. Our team focuses on providing high quality products with reasonable price and tries its best to keep transactions as simple as possible. Please be confident of and enjoy your shopping here! Please feel free to contact us via eBay message system or email.
