Autoclave, Industrial, Lab Size R&d 330 Psi And Vacuum, 450 Deg F

US $16,000.00

Morgantown, Pennsylvania, United States
Mar 28th

Open on mobile:
QR code

Autoclave, Industrial, Lab Size R&D 330 psi and vacuum, 450 DEG F This is a used lab sized industrial autoclave that is vacuum and pressure rated up to 330 PSI at a temperature of 650 deg F. The system consists of a horizontal pressure vessel mounted on a stand and a vertical control cabinet which installs adjacent to the vessel. Chamber has front and rear swinging doors that are held shut with large T-bolts. The rear door gives access to the circulation blower motor while the front door gives access to the work area. The vessel is electrically heated with 12kW of heaters and controlled with an scr amp and digital controller interface. There is a circulation blower inside the chamber which requires a steady flow of cooling fluid and this is monitored with a cooling fluid flow switch. There is also a second set of coiling coils for regulating the overall temperature of the chamber. The chamber is pressurized and vented with a two pneumatically operated valves. The control cabinet houses a plc, graphic interface, GI controller, heater SCR, flow switch controller, blower motor starter, push buttons and other fuses and relays. The graphic interface is a programmable controller that shows the actual values and setpoints for both temperature and pressure. Segmented programs can be entered to ramp up and down the setpoints. The control panel has pull-buttons that manually operate some of the functions of the chamber along with warning indicator lights. The system was partially tested by applying power and air pressure. We operated the machine in "manual" mode which gives you the ability to use the front control buttons to pressurize and vent the chamber, operate the blower, vacuum pump relay, cooling coil and set the chamber temp from the graphic interface controller. We could not determine how the "auto" mode was intended to work. The graphic interface is very easy to use and we were able to change the setpoint for the temperature from here. The heater system is very powerful and chamber temperature quickly increases and overshoots the setpoint somewhat but after some time the temperature stabilizes and the controller holds the setpoint very accurately. Circulation blower turned on and sounded good. We manually pressurized the chamber by pulling the "pressurize" button to about 25 PSI and it held the pressure for a few hours until we vented the chamber. Pressure is monitored on the graphic interface as process variable #2. We are not sure if the graphic interface controller is suppose to control chamber pressure or only monitor it. The system is in very good overall condition and all of the functions we were able to test worked very well. It was built in 1993 and has been well maintained and cared for and aside from a few scratches it is cosmetically very presentable. Wiring diagrams included Chamber rating: 330 PSI @ 450 deg F (can reach 650 Deg at lower pressures) Work area: Width: 16" Depth to fan: 18 3/4" This does not include recess in door Height in center: 10 1/2" Vessel OD: 24" x 56 Long All the valves on top of chamber are rated for 330 psi or greater. Relief valve set to 330 psi Chamber has 6 ports: Top: two ports supplied by the high pressure valves and piping, one of these has a thermocouple as well Side: Four ports Two have thermocouples installed One for vacuum/pressure One unused Fan motor side: Water inlet and outlet ports Flowmeter installed in line with one 440-480 VAC 21 KVA 3 phase Water supply: 14 GPM, 30-40 PSI Compressed air: 80-100 PSI, 2 CFH Ctrl cabinet: 27x24x78" Autoclave: 55x44x74" Foot print of both clave and cabinet setup:56"W x 55D x 72H Industrial autoclaves could be used for: Materials research, composites, aerospace, carbon fiber, curing, pressure treating wood, vacuum oven, heat treating Specifications: MFG: Advanced Vacuum Systems Model: AC1-1.5-650-300 Serial: 3-1516-7/93 Volts: 440-480 Amps: Phase: 3 Drive: Controls: Manuals: Air: Weight: Lbs Condition: Used Length: Width: Height: All dims inches unless otherwise noted Inventory #: 5820 For more information call 610-286-1655. Please call or email for shipping rates. International purchases: A $40 documentation processing fee will be added to total purchase for items under $150. When communicating with us please use your own email address or call 610-286-1655. We want to know who we are communicating with and we cannot identify specific emails in our inbox using the ebay email system. Send emails to heritageequipment AT gmail.com The new ebay buyer protection program has inspired us to offer all of our items “as-is”.This does not mean that you are buying a machine with deficiencies, known or unknown. What it means is that some of our items will be tested and will include the results in the description and others will be untested but described accurately to the extent that is possible without actually powering up the machine. In addition to this written description you will have the opportunity to view high quality photos of the item. With these two sources of information you will have as much information as possible without being physically here to inspect the machine. Feel assured that we will make a diligent effort to give you an accurate description of the equipment. As a buyer you should be aware that you are buying an expensive piece of equipment at a greatly reduced price and as such you may have to deal with certain unknowns and defective components which were not known and could not be known without full scale setup and operation of the machine. Our experience in dealing with many specialized pieces of equipment has proven this to be a rare occurrence however it is a risk inherent in buying used equipment. The very few times we have had to deal with these issues we have been very helpful in resolving the problem.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Used”
