Automatic Clincher Machine For Metal Channel Letter Making Metalworking Riveting

US $8,699.48

Beijing, China
Jul 22nd

Open on mobile:
QR code

EZ Clincher Riveting Machine Automatic Metalworking Riveting Machine Stocking time is 5-6 weeks Door to Door Delivery! Professional Team,24h Technical Support by Email or Calling! USA EZ Clincher Riveting Machine Automatic Metalworking Riveting Machine Description: Ezletter Clincher is particularly designed for fastening the letter returns and letter backs. Fasten letter backs to the returns of channel letters by clinching, which eliminates the need for fasteners, or adhesives. It uses newest technique power to connect metals without drilling, spot welding and riveting. It's ease-to-use and effective, it can also save power and time. Ezletter Clincher will greatly reduce your channel letter fastening costs and help you outperform the competition with high quality products. Features: 1.Use the pneumohydraulic increasing-pressure cylinder and powered by compress air. 2.Frame with high rigidness and strength. 3.Arrive to the press travels rapidly, no impulsion and no noise. 4.The toolings are made by mold steel form Japan. 5.Electric controller systems are all imported famous brand products. 6.Clinching increases production by quickly, consistently and expertly fastening together different materials of different thicknesses. It allows for a clean, safe work environment because it doesn’t produce fumes or heat and electrical hookups aren’t needed. Specification: Press Force: 2 ~ 2000kn Working Travels: 70mm (2.76in) Press travel: 20mm (0.79in) Throat: 700mm (27.56in) Table Size: 700mm x 800mm (27.56in x 31.5in) Capability Single Max.: 1.0mm Aluminum sheet Adjustable worktable: 0 - 300mm (11.8in) Speed: 40 hits / minute Air pressure requirement: 5kg ~ 6kg (11lbs - 13.2lbs) Voltage: 110V/220VAC,1phase,50 or 60 HZ Power: 1.1KW Air 90psi (6bar) at 1cfm Working size: 1300mm x 750mm x 1970mm (51.2in x 29.5in x 77.6in) Package Size: 1400mm x 870mm x 2170mm (55in x 34.2in x 85.43in) Gross Weigh: 722kg (1588lbs) Remark: The air pump is not included, please prepare it by yourself.The air pump should be above 0.6Mpa. Details: Customer Case:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Capability Single Max	1.0mm Aluminum sheet
Working Travels	70mm (2.76in)
Model	MNM-CLINCHER-01-US
Press travel	20mm (0.79in)
Adjustable worktable	0 - 300mm (11.8in)
Throat	700mm (27.56in)
Speed	40 hits / minute
Table Size	700mm x 800mm (27.56in x 31.5in)
Air pressure requirement	5kg ~ 6kg (11lbs - 13.2lbs)
MPN	6539002440900
Power	110VAC, 1 phase 60 HZ, 1.1KW
Brand	CALCA
Press Force	2 ~ 2000kn
UPC	8414830932172
