Automatic Digital Temperature Controller Thermostat Dc 12v Control Switch

US $120

???, ???, China
Jan 29th

Open on mobile:
QR code

DC12V Heat cool temp Thermostat temperature control switch Thermometer 110°C Description: Control range: -50 ~ 110 °C Input Power: DC 12V Resolution: -9.9-99.9 0.1 °C, other temperature ranges 1 °C Measuring inputs: NTC (10K 0.5%) Waterproof sensor 0.5M Measurement accuracy: 0.1 °C Output range: 1 way 10A relay Control accuracy: 0.1 °C Environmental requirements: -10-60 °C, humidity 20% -85% Hysteresis accuracy: 0.1 °C Size: 48 * 40mm Refresh rate: 0.5S Power consumption: Static current: <= 35MA,attract current:<= 65MA Temperature protection :0-110 °C Display Type: 0.28 " three digital display tube How to use: Connect the power supply and the load, you can supply to the controller, Is displayed as a measured temperature, Press the SET button, the display flashes the temperature, Press + - to set the desired temperature, After setting press SET to confirm return, The controller automatically performs the relay by setting off! Lights, LED status descriptions: Indicator: Off The relay is switched off, Always indicate the relay is closed. LED: Shows LL is the sensor open, showing HH is out of range, the thermostat will be forced to close the relay, the display --- as high temperature protection. Parameter Function: Long press SET 5 seconds to enter the main menu settings, press the + - toggle P0 ... P8 long press SET or 10 seconds of no key activity confirmed their return to the controller Code Code Description Setting range Factory setting P0 Cooling /Heating C/H C P1 Hysteresis setting 0.5-15 2 P2 Highest setting upper limit 110 110 P3 Lowest setting upper limit -50 -50 P4 Temperature correction -7-7°C 0 P5 Delay start time 0-10 Minutes 0 P6 High temperature alarm 0-110°C OFF Off state, long press + - boot to restore the factory settings Package include: 1Pcs Automatic Digital Temperature Controller Thermostat DC 12V Control Switch Contact us: We have much more products, if you need or have any question ,please contact us first .We will try our best to serve .Welcome to wholesale and to be our parter. Thank you so much! Shipping: We Ship to Worldwide, but Italy Russia Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Feedback: The feedback is very important for us.If you are satisfy with us,pleae leave five stars positive feeback,and welcome to our store again,we will supply the good items and service all the time.If you are not 100% satisfied,Please don't leave a neutral or negative but contact us First, we will do our best to solve the problem for you as soon as possible.
