Automatic Identification Transistor Tester Diode Checker Tester 1.8" Tft Display

US $20.36

Shenzhen, China
Jul 4th

Open on mobile:
QR code

Product Description Automatic Identification: Transistors, diodes, dual diode, MOS, SCR, resistors, inductors, capacitors, capacitor ESR. Testing Range: Range of Transistor: Less than 2 (included 2) transistor which is made up of PN junction. Do not have any other resistance components in the interior. Range of Resistance Testing: 0.5-50M Range of Inductance Testing: 0.01mH-20H Range of Capacitance Testing: 25pf - 100000uF Features: 1: One-button measurement operation, the power is automatically turned off by the delay. Shutdown current is only 20nA, support battery operation. 2: Automatic detection of PNP and NPN bipolar transistors, N-channel and P-channel MOSFET, JFET field effect tubes, diodes, double diodes, SCR, resistance, capacitance, inductance. Automatic detection pin definition. 3: Measure the current amplification factor (B) of the bipolar transistor and the conduction voltage (Uf) of the emitter junction. Darlington transistors can be identified by high threshold voltages and high current amplification factors. 4: The protection diode inside the bipolar transistor and MOSFET can be detected and displayed on the screen. 5: Measure the threshold voltage and gate capacitance of the MOSFET. 6: Supports the measurement of two resistances, and the potentiometer can also be measured. If the potentiometer is adjusted to one end of it, the tester cannot distinguish between the middle and end pins. 7: The resolution of the resistance measurement is 0.1 ohm, and the highest measured value is 50M ohm. 8: Capacitance measurement range from 25pf to 100mF (100,000UF). The resolution is up to 1 pF, and the inductance measurement range is 0.01 MH-20H. Otherwise, it will be displayed as a resistor. If the DC resistance of the inductor is higher than 2100 ohms, it will also be displayed as a resistor. In the capacitance test, the VLoss displayed on the screen is the meaning of loss and attenuation. The larger the value, the closer the capacitor is to scrapping! ESR is the impedance. The smaller the value, the better the capacitor performance! 9: It can detect the equivalent series resistance (ESR) of capacitors above 2UF with a resolution of 0.01 ohms. This feature is very important for detecting cpacitive performance. 10: Two diodes can be displayed with the correct direction sign and the forward voltage drop is displayed. 11: The LED is detected as a diode, and the forward voltage drop is higher than the normal value. The dual LEDs are detected as dual diodes. The LED will flash while detecting. 12: The time for each test is about two seconds. Only large capacitance and inductance measurements take a long time. Specification: Color: Black+Grey Material: PCB + Plastic Display: 1.8" TFT Color Display Shutdown Current: 20nA Power Supply: DC9V 6F22 Battery(not included ) Size: 135X70X24mm /5.31''X2.76''X0.94"(approx.) Package included: 1 x Transistor Tester (battery not included) Simple operation instructions: 1, 2, 3 pin free connection, automatic identification type, automatic detection of pin sequence, graphic display, automatic measurement parameters. (For example, if you pick up a triode, you don't have to consider the BCE order of 1, 2, and 3 pins, just plug it in. Then press the test button. It automatically recognizes whether it is a triode, a FET, or a thyristor or resistor. After being identified as a triode, the test is NPN or PNP, and then the BCE order is judged. It is displayed graphically, then tells you the magnification, turn-on voltage, etc. Basically you only need to plug in and press the button. The rest will tell you what it is.) Notice: Please allow 1-3mm error due to manual measurement and make sure you do not mind before ordering. Please understand that colors may exist chromatic aberration as the different placement of pictures. Payment We just accept payment via Paypal Payment must be made within 6 working days There are no hidden fees on advertised price Payment must clear before items are shipped Shipping Please make sure the eBay address matches your shipping address Contact Us If you have any questions or concerns please contact us and send us messages All enquiries will be responded within 24 hours. Fit For Raspberry Pi 3 Model B+ Metal Aluminum Enclosure Case with Cooling Fan 12.36 USD 1.49 USD HF SMA Female Antenna Port RTL SDR Software Defined Radio Receiver 100KHz-1.8GHz 37.18 USD 1.49 USD Fit For JBL Flip 3 Bluetooth Speaker Hollow Carrying Storage Bag Sleeve Portable 9.35 USD 10.75 USD 1.49 USD 13% off Protective Case Storage Bag Shockproof For JBL Flip 5 Wireless Bluetooth Speaker 14.11 USD 1.49 USD 1 Pair Replacement Ear Pads Cushion Cover For Razer Thresher Ultimate Headphones 11.81 USD 1.49 USD For Logitech G602 wireless Gaming Mouse Replacement Pads Mice Skates Mouse Feet 5.57 USD 6.4 USD 1.49 USD 13% off US UK EU AU Plug 4 in 1 AC Power Converter Adapter with Dual USB Charging Ports 13.46 USD 1.49 USD For 2.5 inch Mobile HDD/SSD Hard Disk Outdoor Anti-slip Carrying Protective Box 8.93 USD 10.26 USD 1.49 USD 13% off Dustproof Protector Carrying Bag Sleeve Case for JBL Flip 4 Bluetooth Speaker 13.01 USD Free shipping New BC-4S15D Lithium Battery 2-4S Balance Charger For 2-4 Cells Li-lon/Li-poly 22.19 USD Free shipping Micro-USB/Type-C Smart IR Mobile Phone Remote Control for Android iOS iPhone 12.89 USD 1.49 USD For Raspberry Pi Zero Transparent Acrylic Protector Cover Case with heatsink 5.67 USD 1.49 USD powered by

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Material	PCB + Plastic
Country/Region of Manufacture	China
MPN	Does Not Apply
Display	1.8" TFT Color Display
Shutdown Current	20nA
UPC	Does not apply
