Automatic Transfer Switch100 Amp, 120/240v, 1-phasewith Generator Exerciser

US $960

Oscoda, Michigan, United States
Jan 31st

Open on mobile:
QR code

The GE Zenith ZTX Automatic Transfer Switch complements remote start generator sets allowing the standby power system to be fully automatic. A full range or ratings are available from 40 amps to 400 amp with indoor and outdoor enclosures. Made in USA Application Flexibility The ZTX Automatic Transfer Switch combines reliability and flexibility in a small, economical package for transferring loads between the utility and generator sets. The XTX Transfer Switches work together with any remote-start generators using two-wire control. The control monitors utility and emergency standby power generator set power. When utility power fails or is unsatisfactory, the control starts the generator set and transfers the load to the generator set. The transfer panel immediately senses when utility power is restored. It automatically transfers back to utility power, shutting down the generator and instantly resetting itself for the next power interruption. No action is required by site staff. Enclosures The transfer panel and control are mounted in a single door NEMA 1 (indoor) or 3R (outdoor) enclosure. Positive Interlocking Mechanical contactor interlocking prevents simultaneous closing of normal and emergency contacts. Independent break-before-make action positively prevents dangerous source-to-source connections. Microprocessor Control Reliable, microprocessor based control system with undervoltage monitoring of the utility and voltage and frequency sensing of the generator, standard time delays. This switch comes standard with GE Zenith's MX60 control panel (supersedes the R-M4 control panel). This controller provides timing functions, voltage & frequency sensing, exerciser and operates the external membrane keypad/indications. Agency Approvals Complies with NEMA ICS 10 Conforms to applicable requirements for NFPA 70, 99 and 110 Listed to UL 1008, CSA, IEC listed to 240 VAC 50/60 Hz Specs Switch Current Rating 100 amps, 2 pole (3rd pole optional) Voltage Rating 120/240V, 1 phase (3 phase optional) Operating Temperature -4F to +149F Operating Humidity 95% relative humidity, non-condensing ZTX Standard Accessories Group - MSTD (see note 1) (CD/P) Exerciser Timer (L1) LED Source 2 (Emergency) position indication (L2) LED Source 1 (Normal) position indication (L3) LED Source 1 (Normal) source availability indication (L4) LED Source 2 (or Emergency) source availability indication (P1) Engine start timer P1 – 3 seconds fixed (T) Retransfer to Source 1 (normal) time delay – 5 minutes fixed (U) Engine stop/cool cool down timer – 1 minute fixed (W) Transfer to Source 2 (Emergency) time delay – 15 seconds fixed (6/P) Microprocessor activated Test Switch - Momentary undervoltage sensing of utility source: pickup 90% of nominal dropout 80% of nominal voltage & frequency sensing of generator: 90% voltage pickup 95% frequency pickup Exerciser Clock electronic design, field adjustable for 7, 14, 21 or 28 day exercising with or without load transfer Battery Charger not included (order separately if required) UL Withstand & Closing Ratings 200,000 amps when used with properly rated fuse 30,000 amps when used with properly rated circuit breakers Lug Capacities 3/0 to #8 AWG per pole Nominal Dimensions (H x W x D) 18" x 18" x 8" (not for construction, special options may increase size) Weight 43 lbs. Warranty 1 year limited, no extended warranty available Some of the popular model/types that can be ordered at the bottom of this page (2 pole, NEMA 1 or 3R, 120/240V 1 phase, 3 W, 60Hz) Current Numbering Scheme: ZTX000M60010B-ZEC01ZVC20M060 ZTX000M60010B-ZEC3RZVC20M060 Former Numbering Scheme: ZTX10MX60BC02 ZTX10MX60BS02

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Gently used. In excellent condition. Cables included”
