Automationdirect Gs2-21p0 Variable Frequency Ac Motor Drive Vfd, 1 Hp, 230v

US $900

  • Colorado Springs, Colorado, United States
  • Jun 9th
Input:   200-240V  50/60 Hz 1PH or 3PH 11.5/6.3 Amps Output:  0-240V 1.0 HP 5 Amps 1.9 KVA 3PH Features:  • Simple Volts/Hertz control  • Sinusoidal Pulse Width Modulation (PWM)  • 1-12 kHz carrier frequency  • IGBT technology  • Starting torque: 125% at 0.5 Hz/150% at 5 Hz  • 150% rated current for one minute  • Electronic overload protection  • Stall prevention  • Adjustable accel and decel ramps  • S-curve settings for acceleration and deceleration  • Automatic torque compensation  • Automatic slip compensation  • Dynamic braking circuit  • DC braking  • Three skip frequencies  • Trip history  • Programmable jog speed  • Integral PID control  • Removable keypad with speed potentiometer  • Programmable analog input  • Programmable analog output  • Six programmable digital inputs  • Two programmable relay outputs  • RS-232/485 Modbus communications up to 38.4 Kbps.  • Optional Ethernet communications  For more details, see GS2-21P0
