Autoranging In Circuit Esr Capacitor Resistance Low Ohm Meter 0.001 To 100r

US $73.00

HongKong, Hong Kong
Jan 29th

Open on mobile:
QR code

# A023 AutoRanging In Circuit ESR Capacitor Resistance /Low Ohm Meter Tester 0.01 to 100R Product Description Item Description: Feature: Autoranging capacitor ESR and Low Ohm Meter Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. Using true 100KHz square wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. In the market, there is some technique using short pulse method to testing, but the value will be varying vs the capacitance and sometimes reading is different from the manufacturer's value. What is ESR of capacitor? There is a series resistor inside capacitor, using 100kHz to remove the impedence 1/(2*pi*F*C), the impedence become small, and we can then measure the true series resistor value. A bad E-capacitor will have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. Using this theory, we can measure the capacitor is bad/ damaged or good in condition. Because our ESR meter only apply less than 15mV DC or pk to pk on a good capacitor, so we can use it as in circuit test. Because this low voltage, it can not turn on the semiconductor inside a circuit under testing. During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. *Dual terminal, for fast and easy inspect general capacitor or resistor, a printed ESR table for fast check Range Accuracy (After Zero, tested with 1,10,100R resistor) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value 0.000 to 1.000R 1%+2Digit ~0.4s 1.000 to 10.00R 1%+1Digit ~0.4s 10.00 to 100.0R 2%+1Digit ~0.4s Specification: Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range Measuring voltage: <~40mV RMS (TESTING VOLTAGE) Clamping voltage: ~0.15V (open voltage) Battery 2X AA 1.5V battery External Power: 5V micro USB Operating current 0.02A Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. 3) 1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. 4) Backlight: LCD backlight will on during power on 5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. 6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. 8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package Content: 1 x ESR Capacitor Resistance Low Ohm Meter 2 x test probe Important Note: Our goal is to achieve 5-star rating of each transaction. If you are not 100% satisfied,PLEASE don't leave a neutral or negative but contact us by Ebay message or email First so that we can help you. Payment: We ONLY accept paypal We appreciate prompt payment and look forward to your business in the future. Shipping: Item will be shipped within 1-2 working days after full payment is received. We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. We ship to worldwide by post air mail it will cost about 15-20 business days!( Holliday time may longer cause post office need process more packages) Return Policy: In the unlikely event that a return is request, all returns must include all original items undamaged, in re-saleable condition. Refund request is available within 1 weeK and Exchange request is available in 1 months after parcel received & returning the item as the same condition as received. About Us: Please contact us if the item has not arrived within 30 days for any reason. We reserve the right to refuse the order for all non-registered bidders which is reported from eBay. Please bid ONLY if you agree to the above terms. Your 5-star positive feedback will be highly appreciated.. Please contact us before leaving a negative feedback. We would try our best to help you solve the problem. Please allow us to reply your email within 1-2 Days. If there are any issues with the purchase, please contact us at ebay message or Email, We will reply you ASAP. Engineered for professional eBay sellers!
