Avr Atmega16 Dem2 Demo Development Board Lcd & Usb

US $91

shenzhen, China
Jan 29th

Open on mobile:
QR code

????? You are purchasing AVR ATMEGA16 Dem2 Demo Development Board LCD & USB(DB-DA11211) Read Notice Tips carefully under the pictures before you buy them. Upgrade shipping to TNT express or Regitstered Air Mail Service: For all bills with final value over $19.9, we will use registered air mail to ship them for free. Otherwise if your bill is less than 19.9 and you want registered airmail shipping, please add $2 when finishing payment. For all shipping to West and North Europe, USA, Canada, and Australia, we provide a $10 upgrade service to TNT express, no matter how many items you purchase or what the final weight is. Items will arrive in 3-5 working days and get much better care in the shipment. We strongly suggest our customer to choose this service. We provide a great discount in UPS and FEDEX service to USA and Canada too, contact us for more information. EU countries list: UK, Denmark, Finland, France, Greece, Ireland, Luxemburg, Germany, Italy, Netherland, Norway, Portugal, Spain, Swiss, Switzerland and Malta. Do not adjust the final amount when finishing payment if you are not going to upgrade your shipping. Picture Showcase Description Brief Introduction: This demo board provides the application designer with a low cost development tool to become familiar with ATMEGA16 architecture, high performance peripherals. The board is populated with one ATMEGA16 IC, a 20*2 character LCD, four digits 7-segment LED display, three tactile switches, LM75 IIC digital temperature sensor, a USB mini-B socket, a buzzer, 10-pin IDC connector and LED indicators. Powered via USB mini-B socket, several program functions including temperature measurement, backlight adjustment and contrast adjustment, are sel ectable via a menu system displayed on the LCD. Both LCD and 7-segment LEDs can be used to display current temperature in °C and °F. In addition, connecting this demo board and PC with a USB cable, you can also see more detailed information via Hyper Terminal. To program this board via 10-pin program/debug port, you may choose STK500 USB Programmer by Sure Electronics. Net weigt:140g / 5.0oz Features: Size:119.40(L) x 73.40(W) ± 0.2mm Mini USB power supply ATMEGA16 microcontroller. Its I/O ports are drawn out for convenient reach. 12 MHz high-speed crystal oscillator. 10 pin ISP socket. 24C02N IIC EEPROM on board. LM75 IIC digital temperature sensor. There is a 20*2 character LCD module on board. Pre-installed 4-digit 7-segment LEDs is under LCD module. They could be workable after removing LCD module. Use ULN2003 Darlington transistors array to drive LED segments and speaker. LCD module contrast can be adjusted by LM358 dual OP-Amps or Potentiometers R28 There are 3 function keys connected to RESET, PC7 and PC6 pins. One Power indicator (Green). Four red port indicators are connected to PA0-3 Specifications: Operating Temperature -10°C to +55°C Storage Temperature -20°C to +75°C DC current per I/O pin 20.0mA sink and draw Minimum Load on speaker port 2ohm Applications: Experience in temperature measurement, contrast adjustment, backlight adjustment, LED and LCD display, etc Experience in programming the board Package Included: AVR ATMEGA16 Dem2 Demo Development Board x 1 16*2 Characters LCD Module,No Backlight x 1 Mini USB Cable x 1 Note: The accessories might be a little different from what you've seen on webpage since the accessories you received might be from different batch. However, it won't affect your use. Sure Electronics assumes no liability for any ambiguity caused by the product photos Documents: Go to Download Center for Manual, Driver and Tutorial. Keyword: DB-DP115 Shipping & Handling Payment Method Refund and Return
