Avr Development Board Pcb For Atxmeg128a3u Xmega128a3u Usb Programming ....

US $110

Nanning, Guangxi, China
Jan 29th

Open on mobile:
QR code

External programmer is no need,A perfect choice for your Xmega project~~ OverView - CPU: ATxmega 128A 3U(128K+8K BOOT flash,8K RAM & 2K EEPROM,USB2.0 interface ); - Power supply: USB power supply or DC5V External power supply,LM1117-3.3V voltage regulator ; - JTAG debug interface; - PDI debug interface; - Bootloader enable button(also for user button); - Reset button; - power LED; - User LED; - prototyping area for DIY; - All IOs were lead out for further application! /////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// Introduction to Xmega128A3U XMEGA128A3U device now makes easy to implement and use USB. The XMEGA128A3U with USB interface can be factory configured or reprogrammed with a USB boot loader located in the on-chip flash boot section of the controller.This USB boot loader allows performing in-system programming (ISP) from a USB host controller without removing the part from the system, and without any external programming interface other than the USB connector. /////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// Why choose this board for Xmega? - Newest XMEGA microcontroller comes with USB . - Great board with prototyping area for building your Xmega project. - An external programmer is no need,the Xmega bootloader makes programming very very easy. ////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// What's?software used for downloading HEX?And Do I need an external programmer for this board? Atmel provides bootloader and a USB host loader application called FLIP which works with several Windows? OS. Bootloader for Xmega128A3U Microcontroller: http://www.atmel.com/Images/AVR1916.zip FLIP Software for uploading: http://www.atmel.com/tools/FLIP.aspx The XMEGA128A3U microcontroller has been factory configured or reprogrammed with above bootloader located in the on-chip flash boot section of the controller.So you can use the self-programming apllication directly and no need an external programmer. //////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// How to download HEX using FLIP? Once the boot loader is properly recognized and installed on the operating system,the part can be programmed using FLIP. This section gives a short step-by-step introduction about how to use FLIP to program a part. For detailed documentation,please refer to the online help for FLIP. .Start FLIP . Select the part from the device selection list available with the ‘Device’ icon. . Select “USB” as communication media available with the “USB cable icon” . . Keep the "KEY/BOOT"button pressed and Open the USB port to connect to the target .Select the .hex file you want to download using “File”-> “Load HEX File” menu. . Select the ‘Erase’, ‘Blank check’, ‘Program’ and ‘Verify’ operation check boxes (1)and press the ‘Run’ button (2) You should get confirmation in the bottom section of the window (3) that the FLASH was successfully programmed and verified. .Press ‘Start Application’ button (4) to execute the loaded application ////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// What's in the CD/DVD rom? 1.Bootloader 2.FLIP software 3.exampls source code 4.SCH file 5.AVR STUDIO,WINAVR and ICC software Pls download there here: http://logifind.oss-cn-hongkong.aliyuncs.com/dev_board/XMEGA128A3U%20MINI%20KIT.rar ////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// Packing List This product should include the following components: 1.XMEGA128A3U mini PCB board(Blue or Red),1 pcs ////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////////// Terms and Conditions Payment: PayPal is the only method of payment that we accept. Shipping: 1.Please confirm your address in paypal, including your Phone number!. 2.All items will be shipped within 72 working hours on receipt of cleared payment and We ship items to Worldwide. 3.To USA:via ePACKET Express Shipping,it usually takes 8-15 working days to receive. 4.To Taiwan,Macao and Hongkong:via SF-Express,it usually takes 1-4 working days to receive. Contact the seller first. 5.To South America:via HONGKONG post,SWISS POST,UK POST or Singapore POST,it usually takes 15-45 working days to receive. 6.To Europe:Germany/Belgium Post,it usually takes 6-15 working days to receive,but there may be some delay to some countries. 7.To others Countries:via HONGKONG post,SWISS POST,UK POST or Singapore POST,it usually takes 10-35 working days to receive. 5.We also provides FAST shipping,like DHL,UPS,feDEX and EMS.Pls tell me if you want to use them,and i will send paypal invoice for fast-shipping fee to you. It usually takes 4-9 workig days to receive. ePACKET(only for American Customers):www.usps.com UK Post:http://www.royalmail.com HongKong Post: www.hongkongpost.com Swiss Post: http://www.swisspost.com Germany Post: https://www.deutschepost.de Belgium Post: www.bpost.be DHL:www.dhl.com UPS:www.ups.com feDEX:www.fedex.com EMS:www.ems.com.cn Returns Policy: 1.We are happy to return any unused item in its original packaging within 14 days of delivery. 2.Buyers are responsible for the round (two-way) shipping cost. Feedback: 1.We'll leave POSITIVE FEEDBACK on receipt of cleared payment. 2.If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. 3.Once any ?problems occured, please contact us first. We'll try our best to work things out.Don't leave your BAD feedback without any communication.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	LogiFind
Country of Manufacture	China
Model	ATXMEG128A3U MINI BOARD
