Avtech Avh-hv1-c-p-os Nanosecond Pulse Generator High Voltage

US $1,880.00

  • Santa Fe, New Mexico, United States
  • Jan 29th
Open on mobile:
QR code
Avtech AVH-HV1-C-P-OS Nanosecond Pulse Generator This is a Avtech AVH-HV1-C-P-OS Nanosecond Pulse Generator with user manual. The Model AVH-HV1 is a low jitter high amplitude pulse generator featuring a 10% rise time, a pulse width of 1 ns, amplitudes from 0 to 100 volts, and pulse repetition frequencies from 100 Hz to 100 kHz. The pulse repetition frequency is set by the internal clock oscillator which is controlled by a four position range switch and a one turn control. Amplitude is also controlled by a one turn control. Output polarity is positive. A delay control and sync output is provided for sampling scope triggering purposes. The units can also be triggered externally using a TTL level pulse. The propagation delay in the externally triggered mode is typically 50 ns. A DC offset or bias insertion option is provided. The circuit for this is similar to Model AVX-T at the output. The required DC offset or bias is applied directly to rear panel solder terminals. Click Here to Download More Info Click Here to Download Test Results Specifications Amplitude Range 0 to 100 V Ambient Temperature Range 0 to 50 °C Synchronization Connector BNC Trigger Connector BNC Offset Range ±50 V Pulse Width 1 ns Output Impedance 50 Ω Rise Time 10% Output Polarity Positive Frequency Range 0 to 100 kHz AC Power 120/240 V, 50/60 Hz Trigger Jitter ±15 picoseconds Output Connector SMA Retail Price $7,998.00 Inspection by a Hofstra Group technician allows us to guarantee this hardware to perform to your satisfaction. This item carries a 7-day unconditional right of return and a 90-day warranty. In the unlikely event that you need to return it, we will arrange and pay for return shipping in addition to refunding the purchase price and original shipping. Please review our Sales Agreement for more information. Please note that export of this item is controlled for some countries. Export is possible, but may require a license. It is not guaranteed that a license will be granted by the BIS, in which case the sale will be canceled. Please enquire for details.  _gsrx_vers_525 (GS 6.6.5 (525))
