Ay-3-1015d Universal Asynchronous Receiver Transmitter 276-1794 Radio Shack Nos

US $336

Spokane, Washington, United States
Jun 24th

Open on mobile:
QR code

AY-3-1015D UNIVERSAL ASYNCHRONOUS RECEIVER TRANSMITTER 276-1794 RADIO SHACK NOS Click to Enlarge Description : This Auction Listing is For: A Vintage Electronic BRAND NEW ITEM IN ORIGINAL BOX (When Displayed in Photo) AY-3-1015D UNIVERSAL ASYNCHRONOUS RECEIVER/TRANSMITTER PLUS WE ALSO INCLUDE THE TECHNICAL DATA SHEET MANUAL !! RADIO SHACK ARCHER NEW OLD STOCK (NOS) IN ORIGINAL BRAND NEW SEALED PACKAGE MICROPROCESSOR / MICROCONTROLLER IC AY-3-1015D MICROCHIP 31015 AY31015D DESCRIPTION The Universal Asynchronous Receiver/Transmitter (UAR/T) is an LSI subsystem which accepts binary characters from either a terminal device or a computer and receives/transmits this character with appended control and error detecting bits. All characters contain a start bit, 5 to 8 data bits, one or two stop bits (11/2 stop bit capability) and either odd/even parity or no parity. In order to make the UAR/T universal, the baud, bits per word, parity mode, and the number of stop bits are externally selectable. All inputs and outputs are directly compatible with MTOS/MTNS logic, and also with TTL/DTL/CMOS logic without the need for interfacing components. All strobed outputs are three-state logic. FEATURES ? DTL and TTL compatible ? no interfacing circuits required ? drives one TTL load ? Fully Double Buffered ? eliminates need for system - synchronization, facilitates high-speed operation ? Full Duplex Operation ? can handle multiple bauds (receiving-transmitting) simultaneously ? High Speed Operation ? Three-State Outputs ? bus structure capability ? Low Power ? minimum power requirements ? Input Protected ? eliminates handling problems ? Single Supply Operation ? External reset of all registers except control bits register ? 0 to 30K baud ? Pull-up resistors to VCC on all inputs NEW OLD STOCK (NOS) CLICK HERE TO SEE ALL ELECTRONICS ON SALE AVAILABLE THANK YOU FOR BIDDING ON OUR AUCTIONS! About Us: WE PACK WITH TLC AND SHIP WITH EXPEDIENCY. TRUSTWORTHY, REPUTABLE SELLER TLC Oldies But Goodies Antiquities, Rarities and Collectibles A Family Business (In The Antiquities and Collectibles Business) for More Than Three Decades! WE SHIP USING THE MOST COST-EFFECTIVE AND SAFE MANNER TO ENSURE A PLEASANT BUYING EXPERIENCE. On Aug-04-15 at 14:30:17 PDT, seller added the following information: Every buyer gets a MyStoreRewards invitation for cash back inkfrog terapeak inkFrog Analytics
