B+K Precision Spectrum Analyzer 2625, US $3500 – Picture 0
B+K Precision Spectrum Analyzer 2625, US $3500 – Picture 0

B+k Precision Spectrum Analyzer 2625

US $3500

  • Arden, North Carolina, United States
  • May 27th
Open on mobile:
QR code
B+K Precision Spectrum Analyzer 2625Comes with:  Deluxe Carrying Case (Model LC-210)   Antenna  Instruction Manual Used only a few times, in excellent condition. New units sell online for $2195.00. Specifications Frequency 1.05GHz (1050MHz) Frequency range 0.15 MHz to 1.05GHz (1050MHz) (-3dB) Center frequency display accuracy +-100kHz Marker accuracy +-(0.1% span + 100 kHz) Frequency display resolution 100 kHz (4 digit LED) Frequency scanwidth 100kHz/div to 100MHz/div in 1-2-5 steps and 0Hz/div (Zero Scan) Frequency scanwidth accuracy +-10% Frequency stability Drift: < 150kHz/hour IF Bandwidth (-3 dB) Resolution: 800 kHz and 20 kHz. Video-Filter on: 4 kHz Sweep rate 43Hz AMPLITUDE Amplitude range -100dBm to + 13 dBm Screen display range 80 dB (10 dB/div.) Reference level -27 dBm to + 13 dBm (in 10dB steps) Reference level accuracy +-2 dB Average noise level -99dBm (12.5kHz BW) Second and third harmonic <-75dBc Third order intermod. -70dBc (two signals > 3MHz apart) Log scale fidelity +-2dB (without attn.) 250MHz IF gain 10 dB adjustment range INPUT Input impedance 50 Input connector BNC Input attenuator 0 to 40 dB (4 x 10 dB steps Input attenuator accuracy +1 dB Maximum input level + 10 dBm, +-25 VDC (with 0 dB attenuation) +20 dBm (with 40 dB attenuation) TRACKING GENERATOR (Model 2630 & 2635) Output level range -50 dBm to + 1 dBm (in 10dB steps and var.) Output attenuator 0 to 40 dB (4 x 10 dB steps) Output attenuator accuracy +-1 dB Output impedance 50 (BNC) Frequency range 0.15MHz to 1050MHz Frequency response +-1.5dB Radio Frequency Interference (RFI) <20dBc GENERAL Operating temperature 50 0 to 122 0 F (10 0 C to 50 0 C) Display CRT. 6 inch, 8 x 10 div. internal graticule Trace rotation Adjustable on front panel Line voltage 90-260VAC, 50/60 Hz (125V, 400Hz) Power consumption approx. 20W Max. ambient temperature 14 0 to 104 0 F (-10 0 C to +40 0 C) Protective system Safety Class 1 (IEC 348) Weight approx. 13.2 lbs. (6.0 kg) Dimensions (HxWxD) 4.9x11.2x15'' (125 x 285x380mm)
