Babel Buster 10/100 Modbus Tcp To Lonworks Gateway

US $95.00

Fairfield, Ohio, United States
Jun 9th

Open on mobile:
QR code

Older Stock, Never Used. Babel Buster 10/100 is a fully configurable universal LonWorks to Modbus/TCP gateway. The Modbus master is used to make Modbus/TCP devices accessible on a LonWorks network. The Modbus slave is used to make LonWorks devices accessible on a Modbus/TCP network. As a Modbus master (client), Babel Buster 10/100 can poll multiple Modbus slave IP addresses, and can be bound to any number of LonWorks devices. As a Modbus slave (server), Babel Buster 10/100 responds to a single IP address, and may be bound to any number of LonWorks devices. Babel Buster 10/100 operates as both client and server concurrently, with master and slave functionality enabled on an object by object basis. LonWorks network variable data is translated to Modbus register data, and vice versa. Modbus polling rates and LonWorks network update rates are fully configurable. Register mapping and network variable types (SNVT) are fully configurable. The LonMark Certified Babel Buster 10/100 conforms fully to LonMark version 3.3. The only tool required to configure Babel Buster is LonMaker version 3. • Universal, fully configurable • You pick the Modbus register • You pick the Scalar SNVT type • No extra software or drivers to buy • LonWorks TP/FT-10 (FTT-10A) to Modbus/TCP Gateway • Auto-sensing 10BaseT/100BaseT Ethernet • Static IP assigned from LonMaker, or BOOTP/DHCP • Translate 58 LonWorks variables to Modbus registers • LonMark Ver. 3.3 Sensor & Actuator Functional Profiles • Modbus “coils”, input registers, holding registers • Single or double Modbus registers • Signed, unsigned, IEEE 754 • All scalar (non-structured) LonMark SNVT types supported • SNVT_switch & SNVT_state also supported • SNVT types dynamically assignable via LonMaker • Modbus registers dynamically mappable via LonMaker • Modbus registers may be scaled (x10, x0.1, etc.) • Min/max send time, send on delta configurable per point • Modbus (master) polling interval configurable per point • Object override supported on point by point basis • Bidirectional communication between LonWorks & Modbus • LonMark certified, version 3.3 • 3150L Neuron® Chip, 48K Flash memory, 10K RAM • TP/FT-10 (FTT-10A) transceiver • Powered by 10-30VDC or 12-24VAC 50/60 Hz • Power Consumption: 0.1A @ 24VDC • DIN rail mounting, 100mm H x 70mm W x 60mm D • 10BaseT/100BaseT standard RJ-45 connector • LED indicators for LonWorks, Modbus, Ethernet link status • Pluggable screw terminal blocks • Operating temperature -40°C to +85°C • Humidity 5% to 90% • FCC Class B, CE Mark Support CD download: http://www.csimn.com/CSI_pages/BBConfig.zip

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Control Solutions
MPN	Babel Buster 10/100
Model	Babel Buster 10/100
