Balluff Contrast Sensors Bkt M-15c-u-s4

US $500.00

  • Hidalgo, Texas, United States
  • Jan 29th
Open on mobile:
QR code
Characteristic data Operating voltage 10...30 V DC Connection Connector, M12x1-S04 Switching freq. f max. 10000 Hz Indicator Ready - LED GN Duration of time function 20 ms Input function Same function as key Setting Contrast (switching point), Key lock on/off, Time function on/off, Lighton/ dark-on, Switching output PNP/NPN Time function Turn-off delay Adjuster Key (2x)/Slide switch (3x) Short-circuit protected Yes Protected against polarity reversal Yes Enclosure Type per IEC 60529 IP67 Optical data Principle of optical operation Light scanner, fixed focus Switching function, optical Light-on/dark-on Light spot size, typical 1.5 mm x 5 mm at 9 mm Light type White light Wavelength 400...700 nm Ambient light max. 5,000 Lux Sensing range 7...11 mm Sensing distance Sn Sn = 9 ±2 mm Electrical data Rated operating voltage Ue DC 24 V DC Effective operating current Ie 200 mA Ripple max. (% of Ue) 10 Switching output PNP/NPN (1x) Switching function NO/NC Load resistance RL min. 2,2 kOhm Turn-off delay toff max. 0,050 ms Turn-on delay ton max. 0,050 ms No-load current max. Io at Ue 80 mA Voltage drop Ud max. (at Ie) 2,0 V Analogue output Analog U Value range analogue 0...5.5 V Mechanical data Beam characteristic Focused Connector type M12x1-S04 Sensing surface material Glass Housing material GD-Zn Oberflachenschutz Painted Mounting type Screw M5 Design Block, rotatable connection Ambient temperature -10...55 °C Basic data Basic standard IEC 60947-5-2 Additional features Optical can be rotated (light exit 0°/90°), vertical light spot. A new, unused item with very slight signs of wear. The item missing the original packaging.
Condition New other (see details) :
A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes “A new, unused item with very slight signs of wear.”
