Barber Colman 14-15 14" X15" Hobber Mechanical

US $13000

Machesney Park, Illinois, United States
Nov 12th

Open on mobile:
QR code

Offered by Machine Tool Builders Machesney Park, IL. Please note: Buyer is responsible for rigging and shipping from our facility to yours. Machine Tool Builders (MTB) can assist with logistics if needed. We also offer a Recertification Program as stated below for an additional fee. Please contact Anne at MTB for questions, arrangements or additional services.(815) 636-7502 Learn more about MTB on our website. machinetoolbuilders dot com Description Model Manufacturer Barber Colman Model 14-15 Serial Number 1221 Year of manufacture 1967 Mechanical Specifications Pitch rating (Ideal Conditions) 3.5 DP 7.257143 Mod Maximum workpiece diameter 14.000 in 355.6 mm Maximum facewidth 15.000 in 381 mm Maximum radial center distance 9.750 in 247.65 mm Minimum radial center distance 2.000 in 50.8 mm Maximum axial travel 15.000 in 381 mm Maximum distance table face to tail center 27.250 in 692.15 mm Maximum distance table face to C/L of hob 18.500 in 469.9 mm Minimum distance table face to C/L of hob 3.500 in 88.9 mm Worktable diameter 8.000 in 203.2 mm Workhead spindle bore 3.125 in 79.375 mm Index worm gear diameter 16.000 in 406.4 mm Worktable Starts 2 Threads Maximum hob diameter 6.000 in 152.4 mm Maximum hob length 5.000 in 127 mm Maximum hob shift travel 3.500 in 88.9 mm Work Spindle Speed Range 64.000 RPM 362 RPM Maximum number of teeth 300 Teeth Minimum number of teeth 5 Teeth Maximum swivel angle -50 deg 50 deg Length 110.000 in 2794 mm Width 92.000 in 2336.8 mm Height 83.250 in 2114.55 mm Main Motor Power 10 HP 7.5 kW Machine Weight 9300 lbs 4218 kg Plant power 480 VAC 60 Hz Features Crowning Differential Automatic 2 cut cycle 2nd cut selectable feed direction Swing away tail center assembly Double Thread Index Worm (Standard Accuracy) Controls Relay Logic Optional Machine Recertification Program All broken electrical wires and cables will be repaired All cycles will be tested and verified as fully functional All defective controls will be replaced or repaired All defective sensors will be replaced All features will be tested and verified as fully functional All filters will be changed All worn hoses will be replaced Coolant system checked for problems Coolant tank and chip collection system cleaned Hob head will be checked for problems Hydraulic system drained and cleaned Machine will be thoroughly cleaned Ways and gibs checked for problems Work table drive system checked for problems Machine Includes Integral coolant tank, no conveyor No hob arbor. (One can be quoted additionally) Assortment of change gears Two copies of the operations manuals Two copies of the maintenance documentation 30 Day return warranty on the machine The aforementioned description and listing of specifications and accessory equipment is correct and accurate to the best of our knowledge. However, it should not be considered binding in any regard, as we reserve the right to change and/or alter same without prior notice. Consequently the buyer is responsible for confirming same, upon physical inspection and inventory of the machine(s) and all related accessory equipment.
