New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Gallery Wholesales Power Modules Sensor Modules Wireless Modules Function Modules DIY Modules LCD Modules Development boards Digital Voltmeters Description Battery Tester DC LCD Display Backlight For Current Voltage Resistance Measuring Product Introduction: 1.Model:PZEM-005 2.Operating Volage:2.8~30V DC 3.Testing Voltage:2.8~30V DC 4.Rated Current:10A 5.Measuring Precision:2% Function: 1.Electricity Measurement (voltage,current,load resistance,left electricity quantity) 2.Backlight Function (Key control backlight on/off) 3.LCD Full Display (display voltage,current,resistance,electricity quantity) Display And Key: Display Interface:LCD displays voltage,current,resistance,left electricity quantity Display Format: 1.Voltage:display current input voltage value;display range 2.8~30.0V 2.Current:display current load operating current;display range 0.0~10.0A 3.Resistance:display current load reisitance;display range 0-999 ohm R<10 ohm display 0.01?9.99 ohm 10 ohm <= R < 100 ohm display 10.0?99.9 ohm 100 ohm <= R < 1000 ohm display 100?999 ohm 1000 ohm <= R display "oL" ohm 4.Electricity Quantity:display current battery left electricity quantity;left electricity quantity display is shown as 5 checkers battery symbols,by current voltage and preset end,full voltage to distinguish,so please set battery full voltage and end voltage;every checker represents 20% electricity quntity,when voltage is the same with full voltage,display will be 5-checker electricity quantity;when voltage is the same with end voltage,display will be 0-checker electricity quantity,and so on Key: 1.Backlight Control:everytime power on,it will default backlight is off;you can short press "SET" to let backlight on/off 2.End And Full Electricity Voltage Setting Step 1):long press "SET" for 3s to enter into battery end voltage and full range voltage setting state,then loosen the key Step 2):after entering this state,voltage area will flash display current battery end voltage setting value,and use 0-checker 0 electricity quantity battery symbol to prompt current state is end voltage setting state;at this time,short press "SET"can perform +1 adjustment;long press "SET" can achieve +1 fast adjustment;end voltage settable range is 2.8-29.9V,but it cannot be over full voltage Step 3):when there is no key operation for more than 3s,it will automatically enter into full range voltage setting state Step 4):after entering current state,voltage area will flash display current battery full electricity voltage setting value,and use 5 checkers full electricity quantity battery symbol to prompt that current state is full electricity voltage state;and setting method and range is the same with step 2),but it cannot be over end voltage Step 5):when there is no key operation for more than 3s,it will automatically save and judge data;if data meets the standard and save correct then it will back setting and restore normal display;otherwise,it will display "Err SAu" for 1s then back to normal display About Calibration: 1.Turn off the power,open product bottom cover,short circuit connect with calibration point (located in "W" round hole) 2.Add "10V 1A" standard voltage current 3.Screen will flash display "10V 1A" at this time,prompt current state is calibrating state,calibration condition is "10V 1A" 4.iF calibrates successfully,disconnect the power,disconnect calibration point,and power on again will function well Notice: 1.This product is applacated in indoors,cannot be used in outdoors 2.Don't be over rated voltage and current 3.Avoid wrong connection Shippment Payment Return Policy Feedback About us 1)All items will be shipped to your paypal address .Please update your latest address when you check out,and please make sure to provide us with correct,precise and detailed shipping address. 2)Most of the items will be shipped via Hongkong Airmail/Singapore Airmail .To US customers,we will send the package via E-packet . 3)All items will be shipped in 24 Hours (excluding Sat,Sun & Holiday) after payment received and cleared. For the long-time holiday, we'll post the info on our store and reply you automatically via emails. 4)Tax:We will do our best to help you to clear the goods,and the tax depends on each country custom. 5)If you don't receive items over 30 business days,please make sure to contact us before leaving any neutral or negative feedbacks.We'll try our best to help you solve the problem. 6)The product in our store is free shipping. But the shipping method is different based on your order.If your order is more than $40 ,we will send the items to you with tracking number for free.If your order is less than $40,the registered mail fee is on your side. We could also deliver your item via EMS,DHL or Fedex based on your requirement. 1. We only accept Paypal payment if you buy on ebay. 2. Please make sure you notice the entire desciption and agree to the transaction before buying. 1) If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in 30 days and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2) Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3) Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. 1.Feedback is important to all of us participating on the eBay community. We are always working hard for maintain high standards of excellence and strive for 100% customer satisfaction. So your POSITIVE FEEDBACK is very important.<> 2.Here is an illustration showing how to leave the positive feedback, please follow the following step. Thank you so much. And welcome back to our store again.<> Chip_Partner is a Well-Known Online Supplier specializes in all kinds of IC products and all Consumer Electronics and Intelligent life supplies, such as electronic devices and components, development modules, Power modules, consumptive materials, household items, outdoor products, fishing gear and so on. Chip Partners are on Ebay for almost 10 years, and has owned thousands of registered customers from all over the world. We offer world wide free shipping and have already shipped to more than 150 countries including United Sates, United Kingdom, Canada, Australia, France, Germany, Russia, Italy, New Zealand, Spain, Brazil, Japan, Singapore, Korean, etc. We are more wiling to be your Long-Term Supplier in this filed, as we have these advantage of others: 1.Lowest Pirce, High Quality 2.Best Customer Service 3.Technical Support 4.Mass Quote Sevice 5.Extra Service if you need other items not listed in our shop inkfrog terapeak inkFrog Analytics On Oct-26-16 at 09:14:11 PDT, seller added the following information:On Oct-26-16 at 09:14:13 PDT, seller added the following information:
