Bayite Dc 5-120v 100a Mini Digital Current Voltage Amp Meter Gauge With Hall ...

US $730

US, United States
Nov 13th

Open on mobile:
QR code

bayite DC 5-120V 100A Mini Digital Current Voltage Amp Meter Gauge with Hall Effect Sensor Transformer Description Pattern Name:1. Single Display DC 5-120V 100A w/ Hall coil bayite Hall effect current meter reads current by detecting the magnetic field around the wire, there is no electrical contact which eliminate risk to delicate monitoring equipment and also minimizes safety concerns. The sensor doesn't get hot like the current shunt sense resistor which can have thermal temperature heat dissipation issues. Three display modes: 1, alternately display Amps and Voltage 2, only display Amps 3, only display Voltage Specifications: Measurement Range: + -100A Accuracy: + - 1% Resolution: 0.2A Working current: 7-15mA Power supply: DC 5-120V Product Dimensions: 48mm29mm23mm Mounting hole: 45.5mm25.5mm Sensor hole diameter: 19mm Operating temperature: -4°F - 140°F (-20°C - 60°C) As the resolution is 0.2A, the current reading might be flickering with 0.2A difference. For example, if the current is 1.7A, you might see a 1.7A and 1.9A alternatively. This is normal. If your signal is too weak or you are not getting the resolution you want, you can coil the wire through the current sensor as many times as you want to double, triple, or quadruple the sensitivity or resolution.For example, if your current signal is only 0.03 Amps, you could loop the wire through the sensor 10 times and the signal would by 10X stronger and would appear as 0.3 Amps. Features: Through-hole design: No wiring difficulty. Measure positive or negative current. No current direction limitation. Electrically isolated from high voltage power source which eliminates risk to delicate monitoring equipment and also minimizes safety concerns. Display Voltage or (+ -)Current. Voltage Range: 5V-120V. Current range: 0-100A Large wire capability: Diameter of the hole through sensor is 3/4 inch(19 mm) Loop through sensor multiple times to strengthen signal. For example, if your current signal is only 0.2 Amps, you could loop the wire through the sensor 10 times and the signal would by 10X stronger and would appear as 2.0 Amps. Product Details: Part Number: BYT-VAM-033 Item Weight: 0.8 ounces Product Dimensions: 2.9 x 2.7 x 2.6 inches Pattern: #1. Single Display DC 5-120V 100A w/ Hall coil Power Source: dc Item Package Quantity: 1 Batteries Included?: No Batteries Required?: No Shipping Weight: 0.8 ounces Date First Available: March 24, 2016 Handling We will ship all orders within 1 business day of payment. Delivery We Do Not Ship Outside of the Continental US. Return Policy All items qualify for returns within 30 days of receipt. Buyer is responsible for return shipping on any item that is not damaged. Feedback We take our reputation seriously, we buy and sell online, so we understand the value of trust. If you are unsatisfied with your order, please contact us and we will work with you to resolve it to your satisfaction.
