Bc04-b Master-slave Wireless Bluetooth To Uart Module For Arduino Raspberry Pi

US $29

Shenzhen , China
Jan 29th

Open on mobile:
QR code

BC04-B Master-Slave Wireless Bluetooth Bluetooth to UART Module Industrial More Items In Our Store,Click Here! Description: 1. Adopt the mainstream CSR bluetooth chip, the bluetooth V2.0 protocol standard 2. Serial port module working voltage 3.3 V, Transmission distance is about 15 meters 3. Default baud rates is 9600,it can be set by user. 4. Working status indication, connection and disconnected status signal output, is advantageous for the MCU to track the state of module 5. Core module size: 26.7 x 13 x 2.2 mm 6. Working current:matching: 2~30mA .matched but not communication: 5~6mA communicating: 10mA 7. Sleep current: don't sleep, but support low power mode 8. Used for GPS navigation systems, water and electricity gas meter reading system, industrial control system. 9. Can add bluetooth adapter with bluetooth laptops, computers, PDA and other equipment for seamless connection Specification: 1. Bluetooth protocol:Bluetooth Specification v2.1+EDR 2. USB protocol:USB v1.1/2.0 3. Frequency:2.4GHz ISM band 4. Modulation:GFSK(Gaussian Frequency Shift keying) 5. Transmission power:4dBm, Class 2 6. Sensitivity:-84dBm at 0.1% BER 7. Rate:Asynchronous: 2.1Mbps(Max)/160 kbps,Synchronous:1Mbps/1Mbps 8. Security features:Authentication and encryption 9. Support profiles:SPP(master & slave) 10. Power supply:+3.3VDC 50mA 11. Working temperature:-20~+55 Centigrade 12. Size:26.7mmx13mmx2.2 mm NOTE:BC04-B is the master-slave integrated bluetooth serial port module,Master-slave can be changed by command Maybe You Need 1pcs RS232 / TTL Wireless Bluetooth Transceiver Module IC2272/2262 4 channel wireless remote control kits 4 key wireless remote control 1pcs RF transmitter and receiver kit for Arduino project 433Mhz 315Mhz WL RF transmitter and receiver link kit for Arduino/ARM/MCU 2pcs 2.4GHz NRF24L01+ Antenna Wireless Transceiver Module For Microcontrol 2pcs 2.4GHz Antenna Wireless Transceiver Module NRF24L01+ $11.99+free shipping $4.33+free shipping $1.75+free shipping $1.48+free shipping $3.45+free shipping $3.44+free shipping For more quantity,please contact us. If you need these goods,you can add them to the cart. 1) We accept PayPal payment ONLY. inkfrog terapeak i000000 inkFrog Analytics On Nov-24-14 at 10:06:56 PST, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	USB protocol	USB v1.1/2.0
Security features	Authentication and encryption
Frequency	2.4GHz ISM band
Support profiles	SPP(master & slave)
Modulation	GFSK
Power supply	+3.3VDC 50mA
Transmission power	4dBm, Class 2
Working temperature	-20~+55 Centigrade
Sensitivity	-84dBm at 0.1% BER
Size	26.7mmx13mmx2.2 mm
