Beagle I2C/SPI Protocol Analyzer, US $350 – Picture 0
Beagle I2C/SPI Protocol Analyzer, US $350 – Picture 0

Beagle I2c/spi Protocol Analyzer

US $350

  • St-Hubert, QC, Canada
  • Nov 21st
Open on mobile:
QR code
Fast and secure shipping Free shipping to Canada USA 25$ Rest of the world message me for rates The versatile Beagle™ I2C/SPI Protocol Analyzer is the ideal tool for the embedded engineer who is developing an I2C, SPI, or MDIO based product. The Beagle analyzer provides a high performance bus monitoring solution in a small, portable package. Perfect for engineers in the field and in the lab. Not sure which product is right for your needs? The Product Selector Guide provides a brief summary table of key features for each Total Phase product. Overview Non-intrusively monitor I2C up to 4 MHz Non-intrusively monitor SPI up to 24 MHz† Non-intrusively monitor MDIO up to 2.5 MHz (Clause 22 and Clause 45)‡ Real-Time Data Capture and Display - Watch I2C, and SPI packets as they occur on the bus. Bit-level timing down to 20 ns resolution. Fully Windows, Linux, and Mac OS X compatible Includes full function monitoring tools Low Cost † Actual SPI capture performance is dependent on CPU speed and SPI bus throughput. 24 MHz SPI capture has been tested for typical applications (e.g., captures of a few hundred SPI packets). Depending on user configuration, the maximum achievable capture throughput for continuous streaming applications may be less than 24 MHz. ‡ MDIO monitoring is available in the current versions of the API and version 2.20 of Data Center, which can be downloaded from the Data Center Product Downloads section. What is Included Beagle I2C/SPI Protocol Analyzer unit (1) 6 foot USB A->B cable Rosetta Language Bindings: C/C++, C#, .NET, Python, Visual Basic Examples Software (downloadable from website):Windows USB Drivers Linux USB Hot Plug Configuration files Data Center Software Beagle LabVIEW Driver Datasheets Documentation
