BEI INDUSTRIAL INCREMENTAL OPTICAL ENCODER HS35F 100 R1 SS SM18 MOCK UP, US $300 – Picture 0
BEI INDUSTRIAL INCREMENTAL OPTICAL ENCODER HS35F 100 R1 SS SM18 MOCK UP, US $300 – Picture 0

Bei Industrial Incremental Optical Encoder Hs35f 100 R1 Ss Sm18 Mock Up

US $300

  • Fort Wayne, Indiana, United States
  • May 26th
Open on mobile:
QR code
BEI INDUSTRIAL INCREMENTAL OPTICAL ENCODER HS35F PLEASE LLO AT PDF BELOW FOR PART NUMBER BREAK DOWN http://www.beiied.com/PDFs2/HS35_Incremental_Encoder.pdf Mechanical Specifications Shaft Bore: 1.00”, 0.875”, 0.750”, 0.625”, 0.500”. All are supplied with insulating sleeves. Allowable Misalignment: 0.005” T.I.R. on mating shaft 0.75” from shaft end Bore Runout: 0.001” T.I.R maximum Starting Torque at 25°C: Through shaft version (SS) = 7 in-oz (max); Blind shaft version (BS) = 4 in-oz (max) Bearings: 52100 SAE High carbon steel Shaft Material: 416 stainless steel Bearing Housing: Die cast aluminum with protective finish Cover: Die cast aluminum with protective finish Bearing Life: 7.5 X 10 9 revs (50,000 hrs at 2500 RPM) Maximum RPM: 6,000 RPM (see Frequency Response below) Moment of Inertia: 0.019 oz-in-sec 2 Weight: 18 oz typical Electrical Specifications Code: Incremental Output Format: 2 channels in quadrature, 1/2 cycle index gated with negative B channel Cycles Per Shaft Turn: 1 to 80,000 (see table A, page 25). For resolutions above 5000 see interpolation options on pages 36 and 37 Supply Voltage: 5 to 28 VDC available (see note 5) Current Requirements: 100 mA typical + output load, 250 mA (max) Voltage/Output: (see note 5) 15V/V: Line Driver, 5–15 VDC in, V out = V in 28V/V: Line Driver, 5–28 VDC in, V out = V in 28V/5: Line Driver, 5–28 VDC in, V out = 5 VDC 28V/OC: Open Collector, 5–28 VDC in, OC out Protection Level: Reverse, overvoltage and output short circuit (See note 5) Frequency Response: 150 kHz (up to 5000 cpt resolution; 300 KHz above 5000 cpt, also see note 7) Output Terminations: See table 1 page 65 Note: ITEM HAS OPERATION DOCUMENTATION INCLUDED! Consult factory for other electrical option  14 DAY MONEY BACK GAURANTEE!!! http://www.beiied.com/PDFs2/HS35_Incremental_Encoder.pdf FOR QUESTIONS PLEASE FEEL FREE TO CONTACT US @ 260-710-2866 ASK FOR LEVI SHIPPING PRICES ARE SUBJECT TO CHANGE IF NOT  ACCURATE FREE SHIPPING IN THE UNITED STATES ONLY: IF FREE SHIPPING IS OFFERED ON ITEM!!!
