Belar Fmma-1 "the Wizard" Broadcast Fm Modulation Monitor Analyzer

US $3,245.00

San Diego, California, United States
Jan 29th

Open on mobile:
QR code

DESCRIPTION The Wizard is a microprocessor controlled, digital baseband FM modulation monitor/analyzer that precisely measures peak modulation, peaks per minute, average peak modulation, modulation density, and more. The Wizard can operate with an existing modulation monitor, or it can be configured to replace an existing baseband modulation monitor. The Wizard Software (included with The Wizard) and an IBM compatible personal computer enable real-time graphing, logging, and remote operation. The Wizard features user-defined parameters and settings for maximum flexibility. The two large UP/DOWN menu keys are used to cycle the 16 digit alphanumeric display to the desired menu; the UP/DOWN parameter keys are then used to select the desired setting. The configuration can be saved to non-volatile memory in the unit in the event of a power loss.Two Composite Loop-thru's permit you to "touch up" your modulation remotely through the RS-232 port. For example, you could run the output of your stereo generator through loop-through 1, then through your composite clipper (if applicable), then through Loop 2. You now have the ability to raise or lower the modulation going into the clipper, and to raise or lower the modulation coming out of the clipper - remotely, if desired. A built-in Audio Sentry audio failure alarm alerts you to loss of modulation.When installed at the transmitter, Option 02 measures RF level, AM Noise, and Synchronous AM noise, eliminating the need for a separate AM Noise detector. SOFTWARE The Wizard Software can operate the FMMA-1 remotely and is also used to display real-time graphs. A direct connection or a pair of 2400-bps modems and a phone line may be used. The software is fully password protected with three levels of access. When used for off-air monitoring with the RFA-4 Frequency Agile FM RF Amplifier, The Wizard Software can be used to control the RFA-4, enabling the operator to select among the 10 preset stations or direct dial the desired frequency. The RFA-4's programmed call letters will appear on the computer screen for easy identification of the station you are measuring. MEASUREMENTS Total Peak Modulation in Percent Peak Modulation expressed in kHz Deviation Peaks-per-Minute Count Loop-thru #1 Modulation Loop-thru #2 Modulation Peak Average Modulation Average/Peak Modulation Ratio Peak Minimum Modulation AM Noise (with Option 02) Synchronous AM Noise (with Option 02) RF Level (with Option 02) Pilot Modulation (requires FMS-2 or other source of filtered pilot) Pilot Injection (requires FMS-2 or other source of filtered pilot) SCA Injection (requires SCM-2 or other source of filtered SCA) SETTABLE PARAMETERS Hold Time Peak Modulation Indicator Peaks-per-Minute Indicator Display Hold Display Blanking Peaks-per-Minute Duration Remote Enable Audio Failure Alarm - Time & Modulation Loop-thru #1 Gain (+20% Modulation) Loop-thru #2 Gain (+20% Modulation) Display Resolution (01% or 1%) Time Mode (Real/Past) Peak Weighting (8 time constants) Calibrator (with Option 01) SPECIFICATIONS Accuracy: 0.1% Display: Large 4 digit LED for Total Modulation, 16 segment alphanumeric LED display for menus and parameters Input: Composite or 650 Khz IF (with Option 01) for use with Belar RFA-4, RFA-1A, or DC-4, or RF transmitter sample (with Option 01 and Option 02) Option 01: Precision FM Demodulator with Calibrator Input: 650 kHz IF (From RFA-4, RFA-1A, DC-4, or Option 02) Output: Two 75 ohm buffered, composite Signal/Noise: > 95dB Distortion (IM): < 0.003% Distortion (THD): Unmeasureable (< 0.01%) Option 02: Down Converter and Synchronous AM Noise Detector Frequency Range: 88 to 108 MHz Std. (Specify frequency) Input: 1-10 volts rms, 50 ohms, BNC connector Outputs: 650 kHz IF, 9-pin D connector to Wizard Signal/Noise: > 95 dB AM Noise Range: -17 to -80 dB Synchronous AM Noise Range: -17 to -80 dB

Condition:

Manufacturer refurbished: An item that has been professionally restored to working order by a manufacturer or manufacturer-approved vendor. This means the product has been inspected, cleaned, and repaired to meet manufacturer specifications and is in excellent condition. This item may or may not be in the original packaging. See the seller’s listing for full details. ...

Brand

Monitor
