Belden 9936 15 Conductor 24 Gauge Low Capacitance Cable Per Foot ~ 15C 24AWG, US $250 – Picture 0
Belden 9936 15 Conductor 24 Gauge Low Capacitance Cable Per Foot ~ 15C 24AWG, US $250 – Picture 0

Belden 9936 15 Conductor 24 Gauge Low Capacitance Cable Per Foot ~ 15c 24awg

US $250

  • Costa Mesa, California, United States
  • May 31st
Open on mobile:
QR code
This is an auction for a NEW Belden 9936, 15 Conductor 24 Gauge Stranded, Low Capacitance Double Shielded Cable Being Sold Per Foot for Computer, Data and EIA RS-232 Cabling Applications. This cable has a Grey/Chrome Colored PVC (PolyVinyl Chloride) Insulation Jacket. This Cable has 24 AWG Stranded (7x32) Tinned Copper Conductors, Overall w/Beldfoil (100% Coverage) + TC (Tinned Copper Braid Shield (65% Coverage), and FPE PVC (Foam PolyVinyl Chloride) Insulation on the Individual Wires. This wire is New Old Stock (N.O.S.) and will be cut from a larger roll. >>NOTE: Orders of lengths of More Than 1 Foot Will Be Sent as a Continuous Length.<< FEATURES:   Conductors 15 Conductors Stranded 24 Gauge (15C, 24AWG) Jacket: Overall PVC (PolyVinyl Chloride) Jacket, 80°C, UL AWM Style 2919 ~ 30V RMS Overall Nominal Diameter: 0.345 in. Shielding: Beldfoil® 100% Coverage, w/24AWG Stranded Drain wire Ratings: 80°C, UL AWM Style 2919 ~ 30V RMS Operating Temperature Range: -30°C To +80°C SPECIFICATIONS: Nom. Capacitance Conductor to Conductor: Capacitance ~ 12pF/ft Nom. Capacitance Cond. to Other Conductor & Shield: Capacitance ~ 22pF/ft Nominal Velocity of Propagation: VP ~ 78% Nom. Conductor DC Resistance: DCR @ 20°C ~ 24 Ohm/1000 ft Nominal Outer Shield DC Resistance: DCR @ 20°C ~ 3.56 Ohm/1000 ft Max. Operating Voltage - UL: Voltage ~ 30 V RMS (UL AWM Style 2919), 300 V RMS Max. Recommended Current: Current ~ 1.1 Amps per conductor @ 25°C Overall Cabling Color Code Chart (Number, Color): 1 Black 2 White 3 Red 4 Green 5 Orange 6 Blue 7 White/Black 8 Red/Black 9 Green/Black 10 Orange/Black 11 Blue/Black 12 Black/White 13 Red/White 14 Green/White 15 Blue/White We will combine shipments to save on freight on auctions that are paid for at the same time and shipped in the same box. Please request an invoice if you make multiple purchases on any of our auctions. Payment Terms: PayPal. Payment must be received within 7 days of auction closing. California Residents will be charged sales tax. If you have any questions, PLEASE email me BEFORE bidding! Thank You for looking!
