Belimo Afb24-mft Actuator

US $150.00

Westminster, Maryland, United States
Jan 29th

Open on mobile:
QR code

Belimo Part Number: AFB24-MFT Torque: 180 in-lb [20 Nm] Power Supply: 24 VAC 20%, 50/60 Hz, 24 VDC +20% / -10% Running Time (motor): 70-220 (150) seconds Running Time (fail-safe): <20 sec @ -4 deg.F to +122 deg.F [-20 deg.C to +50 deg.C], <60 sec @ -22 deg.F [-30 deg.C] Technical Data AFB24-MFT, AFB24-MFT-S, AFX24-MFT, AFX24-MFT-S Power supply 24 VAC, +/- 20%, 50/60 Hz 24 VDC, +20% / -10% Power running 7.5 W consumption holding 3 W Transformer sizing 10 VA (Class 2 power source) Electrical connection AFB... 3 ft, 18 GA appliance cable, 1/2" conduit connector -S models: two 3 ft, 18 gauge appliance cables with 1/2” conduit connectors AFX... 3 ft [1m], 10 ft [3m] or 16 ft [5m] 18 GA appliance or plenum cables, with or without 1/2” conduit connector -S models: two 3 ft [1m], 10 ft [3m] or 16 ft [5m] appliance cables with or without 1/2" conduit connectors Overload protection electronic throughout 0 to 95° rotation Operating range Y* 2 to 10 VDC, 4 to 20 mA (default) variable (VDC, PWM, floating point, on/off) Input impedance 100 kO for 2 to 10 VDC (0.1 mA) 500 O for 4 to 20 mA 1500 O for PWM, floating point and on/off control Feedback output U* 2 to 10 VDC, 0.5 mA max Torque minimum 180 in-lb (20 Nm) Direction of spring reversible with cw/ccw mounting rotation* motor reversible with built-in switch Mechanical angle of rotation* 95° (adjustable with mechanical end stop, 35° to 95°) Running time spring <20 sec @ -4°F to 122°F [-20° C to 50° C]; <60 sec @ -22°F [-30° C] motor* 150 seconds (default), variable (70 to 220 seconds) Angle of Rotation adaptation off (default) Override control* min position = 0% mid. position = 50% max. position = 100% Position indication visual indicator, 0° to 95° (0° is spring return position) Manual override 5 mm hex crank (?/16" Allen), supplied Humidity max. 95% RH, non-condensing Ambient temperature -22 to 122° F (-30 to 50° C) Storage temperature -40 to 176° F (-40 to 80° C) Housing NEMA 2, IP54, Enclosure Type 2 Housing material zinc coated metal and plastic casing Noise level =40dB(A) motor @ 150 seconds, run time dependent =62dB(A) spring return Agency listings † cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730- 1:02, CE acc. to 2004/108/EC & 2006/95/EC Quality standard ISO 9001 Servicing maintenance free Weight 4.6 lbs. (1.9 kg), 4.9 lbs. (2 kg) with switch * Variable when configured with MFT options † Rated Impulse Voltage 800V, Type of action 1.AA (1.AA.B for -S version), Control Pollution Degree 3. Programmed for 70 sec motor run time. At 150 sec motor run time, transformer sizing is 8.5 VA and power consumption is 6 W running / 3 W holding. Technical Data AFB24-MFT Power supply 24 VAC, +/- 20%, 50/60 Hz 24 VDC, +20% / -10% Power running 7.5 W consumption holding 3 W Transformer sizing 10 VA (Class 2 power source) Electrical connection AFB... 3 ft, 18 GA appliance cable, 1/2" conduit connector Overload protection electronic throughout 0 to 95° rotation Operating range Y* 2 to 10 VDC, 4 to 20 mA (default) variable (VDC, PWM, floating point, on/off) Input impedance 100 kO for 2 to 10 VDC (0.1 mA) 500 O for 4 to 20 mA 1500 O for PWM, floating point and on/off control Feedback output U* 2 to 10 VDC, 0.5 mA max Torque minimum 180 in-lb (20 Nm) Direction of spring reversible with cw/ccw mounting rotation* motor reversible with built-in switch Mechanical angle of rotation* 95° (adjustable with mechanical end stop, 35° to 95°) Running time spring <20 sec @ -4°F to 122°F [-20° C to 50° C]; <60 sec @ -22°F [-30° C] motor* 150 seconds (default), variable (70 to 220 seconds) Angle of Rotation adaptation off (default) Override control* min position = 0% mid. position = 50% max. position = 100% Position indication visual indicator, 0° to 95° (0° is spring return position) Manual override 5 mm hex crank (?/16" Allen), supplied Humidity max. 95% RH, non-condensing Ambient temperature -22 to 122° F (-30 to 50° C) Storage temperature -40 to 176° F (-40 to 80° C) Housing NEMA 2, IP54, Enclosure Type 2 Housing material zinc coated metal and plastic casing Noise level =40dB(A) motor @ 150 seconds, run time dependent =62dB(A) spring return Agency listings † cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730- 1:02, CE acc. to 2004/108/EC & 2006/95/EC Quality standard ISO 9001 Servicing maintenance free Weight 4.6 lbs. (1.9 kg), 4.9 lbs. (2 kg) with switch * Variable when configured with MFT options † Rated Impulse Voltage 800V, Type of action 1.AA (1.AA.B for -S version), Control Pollution Degree 3. Programmed for 70 sec motor run time. At 150 sec motor run time, transformer sizing is 8.5 VA and power consumption is 6 W running / 3 W holding.

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Model	AFB24-MFT
Brand	Belimo
