Bell & Gosset E617t 1 1/2 Hp Cast Iron Centrifugal Hot Water Circulating Pump

US $1,049.99

Chicago, Illinois, United States
May 20th

Open on mobile:
QR code

Featuring a unitized mechanical seal design with a stainless steel drive mechanism that puts less torsional stress on the seal bellows, this BELL & GOSSETT hot water circulating pump also has an open seal chamber design that helps reduce heat buildup and increases particle removal. Bearings are permanently lubricated with Polyrex™ grease for maintenance-free operation. Pump’s 1-pc. design eases seal replacement while the motor, coupler, seal and impeller can all be repaired or replaced without having to remove the pump from its piping. Model is ideal for use as a replacement pump with the flange-to-flange and intake/suction dimensions identical to many legacy Series 60 models Technical Specifications ItemHot Water Circulating Pump HVAC Circulating Pump TypeHot Water Circulating Pump HP1 1/2 hp Voltage - Pumps208 to 230/460V AC Phase - Pumps3 Connection StyleFlange Inlet/Outlet Size1-1/2 in Shut-Off46 ft Housing Material - PumpsCast Iron Max. GPM @ Head90 gpm @ 30 ft SeriesE-60 Face to Face Dimension13 1/2 in Best Efficiency GPM @ Head67 gpm @ 40 ft Min. GPM @ Head20 gpm @ 46 ft Drive TypeDirect Height13 1/2 in Length21 5/8 in Width9 1/2 in Loop ConfigurationClosed Flange/Union IncludedYes Max. Operating Pressure175 psi Max. Temp.250 Degrees F Amps4.8/2.4 RPM1,750 RPM Number of Speeds1 Thermal ProtectionNo Pump MountIn Line Impeller MaterialBronze Shaft MaterialSteel Mechanical SealEPR/Carbon/Silicon Carbide FeaturesDimensional Interchangeability with Legacy Series 60, Leading Hydraulic Efficiency, Upgraded Unitized Mechanical Seal StandardsASTM B584 Manufacturers Warranty Length3 yr ComplianceCSA, NSF-372 _______________________________________________________________________________________________________________________________________________________________ New condition, includes Xylem Bell & Gossett Fastener Package w/ Flange Gaskets (for Series PL, 60, HV, MF-60). Unit has some cosmetic blemishes, scratches, etc. Upon inspecting the unit, components and internal hardware look to be in new condition. We have not tested the unit. If you have any questions, feel free to send us a message. Please see pictures! Picture's are high resolution, please zoom in to see the details. We try to document and photograph everything to the best of our ability. You will receive what is shown in the photo's above. If it is not pictured, it does not come with the listing. If you are unsure of anything, reach out to us before purchasing the item. Shipped with USPS, FedEx or UPS to the lower 48 states. Handling time set on the listing is 3 business days. We cannot control delays caused by shipping carriers. Delivery dates from eBay are estimated and not guaranteed dates. In some cases, we cannot ship to P.O. boxes. We offer an Expedited Shipping option that is available during checkout. Items valued over $100 will require Insurance and Delivery/Signature Confirmation. Your item(s) will be packaged carefully to ensure they arrive to you safely. We are not accepting returns. Please review the photo's and item description. This is sold as is. If you have any questions, feel free to send us a message. _______________________________________________________________________________________________________________________________ We are not accepting offers via message. If you would like to make an offer, please use the Best Offer feature in the listing. Note: If you submit an offer, it is a binding agreement to purchase the item per eBay policy. If payment is not received within 5 days, an unpaid item case will be opened. We have to do this in order to receive a fee credit from eBay for the sale.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	e617T
Brand	Bell & Gossett
MPN	e617T
UPC	Does not apply
