Benefit High-performance Cnc Router 1 Axis Tb6600 Stepping Motor Driver Board 5a

US $370

Los Angeles, United States
Jun 9th

Open on mobile:
QR code

Frist-Supply World Shipping 7 Days Money Back Benefit High-performance CNC Router 1 Axis TB6600 Stepping Motor Driver Board 5A More.. ?TOP High Performance TB6600HG Microstepping Driver Descriptions TB6600HG is a high performance microstepping driver based on the latest original TOSHIBA high-efficiency TB6600HG IC. The TB6600HG adopts single-chip PWM bipolar sinusoidal chopper to ensure the low vibration and high efficiency. Moreover, the brand new design with BiCD0.13 (45V) process technology on the chipset also ensures maximum 5.0A output current and 45V output withstand voltage. Consequently, as long as the current range of the stepper motor is within 0.2-5 amps, all the 2 Phase or 4 Phase of Nema17, Nema23, Nema24 and small-sized Nema34 stepper motors will work perfectly with this new-type TB6600HG Stepper Driver. If you desire low noise, low heating, and low price, this is an excellent choice for you. For further information, please click on the following links. Comparison between TB6600HG and TB6560AHQ Chipset. Specification of TB6600HG Microstep Motor Driver. Features TB6600HG Microstepping Driver High performance, cost-effective. Automatic idle-current reduction. Supply voltage up to 45V DC. Output current from 0.2~5.0A. Suitable for 2-phase and 4-phase motors. Single-chip PWM bipolar sinusoidal chopper ensures low vibration and high efficiency. 1, 2, 4 (New Mode), 8, 16 adjustable microstep control, motors run more precisely and smoothly. Overload, overcurrent, overheat, overvoltage and undervoltage protection to avoid damaging your computer and devices. Cooling Aluminium Box Design for Cooling, and protect the driver board from being damaged by dirt, dust or other liquids. Applications Suitable for any small-and-medium automatic equipment with CNC controller, such as X-Y-Z tables, labeling machines, laser cutters, engraving machines, and pick-place devices For advising, such as brand, architechture mould, badge, nameplate, display boards, doorplate, furniture decoration, etc.. For processing various pattern mould For carving portrait, scenery, handwriting, sealing, etc.. Power Supply Selection 12~24V DC power supply for Nema 17 stepper motors. 24~36V DC power supply for Nema 23/24 stepper motors. 36~45V DC power supply for Nema 34 stepper motors. Output current of the power supply must exceed the sum of motor rated current. Please SHUT DOWN the power before you plug or unplug the connectors to avoid burning up the board. TB6600HG DIP-Switch Settings Output Current SW1 SW2 SW3 0.2A ON ON ON 0.6A OFF ON ON 1.2A ON OFF ON 1.8A OFF OFF ON 2.5A ON ON OFF 3.3A OFF ON OFF 4.2A ON OFF OFF 5.0A OFF OFF OFF Microstep SW4 SW5 SW6 N/A ON ON ON 1(Full Step) OFF ON ON 2 ON OFF ON 2 OFF OFF ON 4 ON ON OFF 8 OFF ON OFF 16 ON OFF OFF N/A OFF OFF OFF TB6600HG Interface Instruction Connection Diagram for Reference ?TOP I. Electrical Specifications Input voltage 12V-45V(Peak) DC Output current 0.2A-5.0A (Peak) Drive type Pulse + Direction + Enable Signal Control (Single-Chip PWM Bipolar Sine Chopper) Suitable motor Nema17, Nema23, Nema24, small-sized Nema34 (Rated current: 0.2A-5.0A) Net weight 250g Dimensions 105*85*35mm II. Operationg Environment & Other Specifications Cooling Natural Cooling or Fan Forced cooling Operating Environment Environment Avoid dust, oil fog, corrosive gas Ambient Temperature 0 °C- 50°C (32°F - 122°F) Humidity 40%RH - 90%RH Operating Temperature 70°C (158°F) Max Storage Temperature -20 °C - 65°C (-4°F - 149°F) Total Weight Approx. 300g ?TOP 1 x 1 Axis TB6600HG Microstep Driver Board (TB1H) 1 x CD ?TOP 3 Axis CNC Router DIY Kit 5 Axis Breakout Board TB6600HG Stepper Motor Driver 5AAUD 112.79 (Free P&P*) 4 Axis CNC Router DIY Kit 5 Axis Breakout Board 4* TB6600HG Stepper Motor DriverGBP 84.39 (Free P&P*) Shipping Payment Warranty Estimated Delivery Time (subjects to stock availability) USA (excl. Alaska, Hawaii, Puerto Rico) USPS First-Class Package/UPS Ground/USPS Priority 3-7 business days Other Countries (May depart from other stock location) International Airmail Service 12-21 business days Please DO CONTACT AND CONFIRM with us BEFORE you bid IF you: - need the item urgently. - require that the item should be delivered within a certain time. - have any other questions/requirements about delivery. Remarks: *Usually, your order will be dispatched before the next working day after the full payment is cleared when stock lasts. *Notification will be sent after your order is dispatched, please check you email or ebay order records for date of dispatch. *It is not guaranteed that parcel should arrive within the time stated above. However, 95%+ parcels will be delivered within the reference time. *Please contact us if you have any trouble in receiving your orders. We will help you to track them. PayPal: We accept PayPal (Allows you to pay by credit cards, debit cards or echecks securely with NO surcharge) * If you have difficulty to make payment by PalPal please contact us for alternative payment method. Remarks: *Please send payment within 5 days after auction ends. All sales are final, shipping and handling costs are also NOT negotiable. *We will use your PayPal shipping address as the delivery address. *Please make sure that your shipping address is correct. 30 Days Money Back Guarantee: Free Replacement: If you are not satisfied with the item purchased from us. Please inform us in writing(e.g. e-mail, eBay message, fax, letter) within 30 days of receipt of goods. We will guide you to return and refund the item. Please note that the postages / custom fees(if any) spended in such an order are on the customer's cost. If you receive a not-as-described (e.g. defective, incorrect, part missing) item, please contact us when you get the item. We will arrange a replacement as soon as the case is confirmed. Suppliers Warranty: Requirements: We offer ONE YEAR warranty on this product. If your item has any warranty issue please contact us for a satisfying solution. *All qualified returns/replacement must be guided by us. We may not accept your return without informing us in advance. *Customs fee, handling charge, postage and insurance are on customers cost and not refundable. Agreement: By placing an order, you acknowledge that you have accepted the terms and conditions of sale. You are welcome to contact us with any questions.
