Bevel Gearing, Machinery's Reference Book No. 37 (1910) - Reprint

US $6.50

Mebane, North Carolina, United States
Jan 31st

Open on mobile:
QR code

Bevel Gearing, Machinery's Reference Book No. 37, by Ralph E. Flanders, originally published by The Industrial Press, New York, NY, 1910. Reprinted by Nation Builder Books, Leesburg, VA, 2002. 5 1/2 x 8 1/2 softcover, 48 pages. Please note that this is a PHOTOCOPIED reproduction of the 1912 original. The accompanying images were scanned from a reprint, not the original. In the early 1900s, when highly skilled machinists enjoyed the same status and prestige as computer programmers do today, Machinery magazine was essential reading for any industrial executive. Industrial Press, the publisher, approached the most erudite master machinists they could find to write a series of booklets on various specific aspects of machining and manufacturing operations. These booklets were jam-packed with the practical knowledge, hard-earned know-how, and "shop kinks" learned over the lifetime of the foremost machinists in the world. In 1914, these booklets were consolidated into the first edition of Machinery's Handbook, which has remained the world's premier handbook for the metalworking trades for nearly a century. A first edition of Machinery's Handbook sold on Ebay in May 2002 for over $200. Another first edition sold in December 2002 for over $300. Until now, many of the booklets that were published as part of the series that was the origin of Machinery's Handbook were almost as rare. Nation Builder Books is proud to begin reproducing a number of these previously rare booklets nearly a century later. The contents are: Bevel Gear Rules and Formulas Different Kinds of Bevel Gears Rules and Formulas for Bevel Gear Calculations Examples of Bevel Gear Calculations Shafts at Right Angles Acute Angle Bevel Gearing How to Avoid Internal Bevel Gears Systems of Tooth Outlines Used for Bevel Gearing The Cycloidal System Involute and Octoid Teeth Formoid Cutters for Involute Teeth Special Forms of Bevel Gear Teeth Strength and Durability of Bevel Gears The Materials Used for Making Bevel Gears Strength of Bevel Gear Teeth Rules and Formulas for the Strength of Bevel Gears Design of Bevel Gearing Bevel Gear Blanks General Considerations Relating to Design Interchangeable Bevel Gearing Model Bevel Gear Drawing Dimensioned Drawings for Gears whose Teeth are to be Planed Machines for Cutting Bevel Gear Teeth Spherical Basis of the Bevel Gear: Tredgold’s Approximation Principles of Action of Bevel Gear Cutting Machinery Machines for Cutting the Teeth of Bevel Gear by the Formed Tool Process Bevel Gear Templet Planing Machines Bevel Gear Generating Machines Cutting the Teeth of Bevel Gears The Practicability of the Formed Tool Process Cutting Bevel Gears in the Milling Machine Offsetting and Rolling the Blank to Approximate the Shape of Tooth Filing the Teeth Cutting Bevel Gears on the Automatic Gear Cutting Machine Among the machines illustrated in this booklet: Gould & Eberhardt Automatic Machine Gleason Templet-Controlled Bevel-Gear Planing Machine Bilgram Bevel Gear Generating Machine Gleason Bevel Gear Generating Machine

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“New reproduction.”
