usbStick is a mini size 28 Pin USB PIC18F2550 IO Board with 13x input, output, analog and pwm pins. Great tool for signals monitoring (as oscilloscope), data acquisition and circuit troubleshooting at 1mSec/Samples period. The features of iCP12 are listed as followings: Mini size, easy interfacing, high performance and user friendly device Used with PIC18F2550 28-Pin Flash USB PIC MCU Excellent flexibility that allows user to expand the board with plug and play modules Peripheral Features: 13x IO Port (6x 10bit ADC pins, 2x 10 bit PWM/Freq/DAC pins) Serial port emulation (UART Baud Rates: 300 bps to 115.2 kbps) Maximum Voltage: 5Vdc 100mA current output at VDD pin with over-current protection 20MHz oscillator Green LED - power on indicator 2x LEDs (Green, Red) - status indicator ICSP Connector - on-board PIC programming Switch Mode Selection - Boot or Normal mode SmartDAQ v1.3 Features: Sampling channel: 6x Analogs (10 bits ADC) + 7x Digitals (Input/Output) Maximum Sampling rate: 1KHz or 1mSec/Samples Sampling voltage: 0V - 5V (scalable graph) at 5mV Resolution Sampling period: mSec: 1, 2, 5, 10, 20, 50, 100, 200, 500 Sec: 1, 2, 5, 10, 20, 30 Min: 1, 2, 5, 10, 20, 30, 60 Trigger Mode: Larger [>], Smaller [<], Positive edge [?], Negative edge [?] Sampling Mode: Continuous, Single Logging Function: Save Format: Text, Graphic, Both Start Time: Normal, Once Trigger, 24-Hour Clock (Auto Run) End Time: Unlimited, Data Size, 24-Hour Clock (Auto Stop) Recorded Data format: Graphic | text | excel Dimension: Dimension: 7.0cm X 2.3cm X 0.5cm (H) Standard 1x5 2.54mm Pin Socket for ICSP connection Standard 4x6 2.54mm Pin Socket for IO Port connection Remarks: Overvoltage or overcurrent may damage the MCU. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability. Layout: Accessories List: (These accessories would be shipped together) 28 Pin PIC: PIC18F2550 Preloaded Firmware: HID Bootloader + iCP12 DAQv1.3 Firmware iCP12 firmware can be updated using Microchip USB HID Bootloader via USB port NO programmer is required! Firmware Upgrade: First, switch the SW1 to 'A' for bootloader mode and connect it to USB port Then program the iCP12 with provided firmware (iCP12_xx_Firmware.hex) file Disconnect the iCP12 and switch back the SW1 to 'B' for normal operation Photos: with SmartDAQ v1.3 All 6x ADC signals overlap together into a single line: x1, x2, x5, x10 (Zoom Scale) Parallel Recording in 'Text & Graphic Form' at 1mSec Sample Rate (0.5 sec/graph) with 'ioControl' with 'pwmGenerator ' with 'adcStream ' Video: SmartDAQ Demo: (with iCP12 usbStick & iCM32 XYZ Axis Accelerometer) Video Download: Please share it for more great features: [Facebook Share] iCP12v1.0 usbStick: Schematic iCP12 SmartDAQ Firmware: v1.1, v1.2, v1.3, v1.3.2 [New] iCP12 Software Pack v1.2 (Serial Driver, Bootloader, Firmware, SmartDAQ v1.3...): zip HID firmware, ioControl Demo PIC Source Code: contact us FREE Visual Basic 2008 Express Software: Link PIC18F2550 Datasheet: pdf MPLAB IDE 8.40 (93.7MB): zip Old Version: iCP12 Software Pack v1.0 (firmware, bootloader..): zip iCP12 Software Pack v1.1 (Serial Driver, bootloader..): zip Android Apps: SmartDAQ v2.0: Link Supported Device: Arduino UNO, Arduino MEGA 2560, MRP01 - AVR USB Programmer Software: Software 01 - ioControl: Link (Free ioControl VB2008 Source Code): Link (Please Contact Us to get the Source Code) Software 02 - SerialComm: Link Software 03 - SmartDAQ: Link Software 04 - pwmGenerator: Link Software 05 - adcStream: Link More iCP12 usbStick information: Link Third-Party Software: TestiCP12 interface (animations control): Link Tool for Linux and Mac OS X to support iCP12: Link Product Reviews: Embedded Lab - iCP12 usbStick, SmartDAQ and Easy Pulse Sensor: Link Shipment Standard Shipping (Delivery time is 7-30 business days): with Registered Air Mail Expedited Shipping (Delivery time is 3-10 business days): is available to US, Canada, Europe & Australia. P.O. Boxes is NOT supported by Expedited Shipping Expedited Shipping for Europe countries ONLY cover: Austria, Belgium, Czech, Denmark, Finland, France, Germany, Hungary, Ireland, Italy, Liechtenstein, Luxembourg, Monaco, Netherlands, Norway, Poland, Portugal, Slovakia, Spain, Sweden, Switzerland And United Kingdom Please check with us of express shipping for other countries. Tracking number is provided for Standard and Expedited Shipping. You may contact us for the tracking number. We ship within two business day after payment received. We will ship to the Paypal shipping address you entered during checkout process, rather than your Ebay shipping address. We Ship to Worldwide, except China, Somalia, Lubnan and Israel. Payment Payment method: We only accept PayPal Please request total for combined orders. Other Policies We are not responsible for any custom duty or import tax. These charges are the buyer's responsibility. We will leave POSITIVE FEEDBACK after receive the full payment. Please contact us if you are not satisfied with the item when you receive it. Serious Buyer Only! Please place bid only if you agree with all the terms. Warranty Only MANUFACTURING defective product will be offered exchange or store credit. Damage caused by any misuse of product is not covered under warranty. Contact Us Please read our policy and product description before your purchase. We will explain it in detail and satisfy your needs. Feel free to contact us! Email: support@piccircuit.com For more information or Bulk Order, please visit www.piccircuit.com On May-28-11 at 17:13:24 PDT, seller added the following information: Sellers: Get your own map today. Click here now. Simple." apps.froo.com | Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application
